Key reminder & seat belt warning circuit for Lexus SC II facelift (2005-2010)

11 12 13 14 FSR+ FSR- BSW BGND 24 16 FSR- FSR+ AIR BAG SENSOR ASSEMBLY (UNDER FRONT OF CENTER CONSOLE) BLK WIRE BLK/RED WIRE BLU/ORG WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BUCKLE SWITCH BUZZER CENTER J/B (BEHIND RIGHT CENTER OF DASH) COMBINATION METER COMPUTER DATA LINES SYSTEM CTY D-IG FUSE DBKL DRIVER DOOR ECU (IN DRIVER'S DOOR) DRIVER SIDE J/B (BEHIND LEFT KICK PANEL) DRIVER SIDE J/B ECU (BEHIND LEFT KICK PANEL) FUSE GATEWAY ECU (BEHIND RIGHT SIDE OF DASH) GRN/BLK WIRE GRN/RED WIRE HOT AT ALL TIMES HOT IN ACC OR ON PASSENGER SIDE J/B (BEHIND RIGHT KICK PANEL) HOT IN ON OR START IH (UNDER STEERING COLUMN) J/C 13 (BEHIND RIGHT SIDE OF DASH) J/C 17 (LEFT REAR OF LUGGAGE COMPT) LAPB LEFT BUCKLE SWITCH (IN LEFT FRONT SEAT BELT BUCKLE) LEFT DOOR COURTESY SWITCH LT GRN WIRE LT GRN/BLK WIRE MPX MPXB OCCUPANT CLASSIFICATION ECU (UNDER FRONT PASSENGER'S SEAT) OPEN DOOR IND ORG/ WIRE P-IG FUSE PBEW PBLT PNK/BLU WIRE POWER SUPPLY CIRCUIT RED WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT BUCKLE SWITCH (IN RIGHT FRONT SEAT BELT BUCKLE) SEAT BELT IND SPEEDOMETER TELLTALE LIGHT ASSEMBLY FRONT PASSENGER SEAT BELT WARNING LIGHT TRANSPONDER KEY COMPUTER (LEFT SIDE OF DASH, BEHIND GAUGE ASSEMBLY) UNLOCK WARNING SWITCH (BEHIND LEFT SIDE OF DASH) WHT WIRE WHT/BLK WIRE WHT/BLU WIRE YEL WIRE
