Lexus SC II facelift (2005-2010) Cooling fan circuit

10 9 RFC HP BLK WIRE BLU WIRE BLU/WHT WIRE BRN WIRE DRIVER SIDE J/B (BEHIND LEFT KICK PANEL) DUAL ED (REAR OF LEFT FENDER) ENGINE CONTROL MODULE (AT LEFT SIDE OF ENGINE COMPT, IN ECU BOX) ENGINE COOLANT TEMPERATURE SENSOR (ON TOP RIGHT SIDE OF ENGINE) ENGINE ROOM 1 R/B (ON RIGHT SIDE OF ENGINE COMPT, BEHIND STRUT TOWER) ENGINE ROOM 2 R/B FAN FUSE FAN RELAY (ON LEFT SIDE OF ENGINE COMPT, FORWARD OF STRUT TOWER) FAN-2 FUSE HEATER FUSE HOT AT ALL TIMES HOT IN ON OR START IF (AT LEFT KICK PANEL) II (ON LEFT SIDE DASH BRACE) JUNCTION CONNECTOR 1 (IN ENGINE ROOM 2 R/B) JUNCTION CONNECTOR 3 (IN ENGINE ROOM 2 R/B) JUNCTION CONNECTOR 8 (BEHIND LEFT END OF DASH) M+(M) M-(M) M+(S) M-(S) PRESSURE SWITCH (AT UPPER LEFT RADIATOR SUPPORT) RED WIRE RED/BLU WIRE SINGLE VIO WIRE WHT WIRE YEL WIRE
