Lexus SC II (2001-2005) Shift interlock circuit

1 2 3 4 5 6 7 8 9 10 KLS+ BLK WIRE BLU WIRE BLU/RED WIRE CENTER J/B (BEHIND RIGHT CENTER OF DASH) DRIVER SIDE J/B (BEHIND LEFT KICK PANEL) STOP FUSE DRIVER SIDE J/B ECU (BEHIND LEFT KICK PANEL) STPI GRN WIRE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START IG (LEFT SIDE OF STEERING COLUMN) IH (UNDER STEERING COLUMN) INSTRUMENT PANEL J/B (BEHIND UPPER CENTER OF DASH) ORG/ WIRE P-IG FUSE PASSENGER SIDE J/B (BEHIND RIGHT KICK PANEL) RADIO 2 FUSE RED WIRE RED/BLU WIRE SHIFT LOCK CONTROL ECU (UNDER CENTER CONSOLE, NEAR SELECTOR LEVER) SOLENOID STOPLIGHT SWITCH (ON TOP OF BRAKE PEDAL BRACKET) WHT WIRE WHT/BLK WIRE
