Exterior lamps circuit for Lexus SC I (1991-2001)

AUTO AUTOMATIC LIGHT CONTROL SENSOR BLK WIRE BLU WIRE BRN WIRE COMBINATION METER COMBINATION SWITCH DIODE FUSE BLOCK (AT LEFT SIDE OF ENGINE COMPARTMENT, BEHIND BATTERY) FUSIBLE LINK GAUGE FUSE GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HEAD HOT AT ALL TIMES HOT IN ON OR START INTEGRATION RELAY (LEFT SIDE OF DASH) JUNCTION BLOCK 1 (BEHIND LEFT KICK PANEL) JUNCTION BLOCK 3 (BEHIND CENTER OF DASH) LEFT REAR COMBINATION LIGHT LICENSE PLATE LIGHT LIGHT LIGHT FAILURE SENSOR (LEFT REAR SIDE OF LUGGAGE COMPARTMENT) OFF TAIL REAR LIGHT WARNING LIGHT RED WIRE RED/WHT WIRE RIGHT REAR COMBINATION LIGHT STOP FUSE STOP LIGHT STOPLIGHT SWITCH (NEAR BRAKE PEDAL) TAIL FUSE TAIL LIGHTS TAILLIGHT RELAY TURN SIGNAL VIO WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE YEL WIRE YEL/GRN WIRE

BLK WIRE COMBINATION METER COMBINATION SWITCH TURN SIGNAL SWITCH GRN WIRE GRN/BLK WIRE GRN/YEL WIRE HAZ-HORN FUSE HAZARD SWITCH HOT AT ALL TIMES HOT IN RUN I9 (3.0L) (DASH HARN, TOP CENTER OF DASH) JUNCTION BLOCK 1 (BEHIND LEFT KICK PANEL) JUNCTION BLOCK 3 (BEHIND CENTER OF DASH) LEFT FRONT PARKING LIGHT LEFT FRONT SIDE MARKER LIGHT LEFT FRONT TURN LIGHT LEFT TURN SIGNAL IND LT GRN WIRE RED WIRE RED/BLK WIRE RELAY BLOCK 2 (ON LEFT SIDE OF ENGINE COMPT, BEHIND BATTERY) RELAY BLOCK 4 (BEHIND LEFT KICK PANEL, ON FRONT SIDE OF JUNCTION BLOCK 1) RIGHT FRONT PARKING LIGHT RIGHT FRONT SIDE MARKER LIGHT RIGHT FRONT TURN LIGHT RIGHT LEFT RIGHT TURN SIGNAL IND TURN FUSE TURN SIGNAL FLASHER WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE
