Lexus SC I (1991-2001) Cooling fan circuit

1994 VFTC J/B 1 (BEHIND LEFT KICK PANEL) A/C CONTROL ASSEMBLY (BEHIND CENTER OF DASH) A/C SINGLE PRESSURE SWITCH (RIGHT SIDE OF ENGINE COMPT) BLK WIRE BLK/RED WIRE BLU/WHT WIRE C/FAN COMBI- NATION METER COOLING FAN ECU (BEHIND RIGHT SIDE OF DASH) DATA LINK CONNECTOR 1 (AT LEFT REAR SIDE OF ENGINE) ECU-IG FUSE ENGINE CONTROL MODULE (BEHIND LOWER RIGHT SIDE OF DASH) GRN WIRE HOT IN RUN OR START IDL TAC COOL HP TH+ TH- IDLO IGB SOL+ SOL- 2 3 4 5 6 7 8 9 10 LT GRN WIRE LT GRN/RED WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE SHORT CONNECTOR SOLENOID VALVE (COOLING FAN) (AT LEFT FRONT OF ENGINE) WHT WIRE WHT/BLK WIRE WHT/GRN WIRE
