Front climate control seats circuit for Lexus RX V (2022-2024)

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM ECU-B 3 FUSE ENGINE ROOM J/B 1 EPS-IGR FUSE GRN WIRE HOT AT ALL TIMES HOT W/ IGR 1 RELAY ENERGIZED HOT W/ IGR 2 RELAY ENERGIZED HTR INP STD 2 FUSE LEFT FRONT SEAT CUSHION HEATER ASSEMBLY LEFT SEAT HEATER CONTROL SUB-ASSEMBLY LT BLU WIRE MAIN BODY ECU METER-IGR FUSE PNK WIRE POWER DISTRIBUTION BOX ASSEMBLY PPL/BLU WIRE RED WIRE RIGHT FRONT SEAT CUSHION HEATER ASSEMBLY S/ HTR 1 RELAY S/HTR F/L FUSE S/HTR F/R FUSE SWR THR+ VIO WIRE W/ CLIMATE CONTROL SEAT W/O CLIMATE CONTROL SEAT WHT WIRE WHT/BLK WIRE YEL WIRE

AIR CONDITIONING AMPLIFIER ASSEMBLY BBS BFB- BLK WIRE BLU WIRE COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM CTB ENGINE STOP, START ECU EXCEPT HYBRID GRN WIRE GRY WIRE IGR LEFT SEAT BACK CLIMATE CONTROL BLOWER LEFT SEAT CUSHION CLIMATE BLOWER SUB-ASSEMBLY LOUT LT BLU WIRE LT GRN WIRE PNK WIRE PPL PPL EP PPL/BLU WIRE RED WIRE RIGHT SEAT BACK CLIMATE CONTROL BLOWER RIGHT SEAT CUSHION CLIMATE BLOWER SUB-ASSEMBLY RIGHT SEAT HEATER CONTROL SUB-ASSEMBLY ROUT SG-7 SIGN SWR TSL TSR VIO WIRE W/ CLIMATE CONTROL SEAT W/O CLIMATE CONTROL SEAT WHT WIRE WHT/BLK WIRE YEL WIRE
