Lexus RX V (2022-2024) Battery cooling fan circuit

2.4L TURBO HYBRID 2.5L TURBO HYBRID BATT FAN 1 FUSE BATT FAN 2 FUSE BATT FAN FUSE BATT FAN RELAY BATTERY COOLING BLOWER ASSEMBLY BATTERY COOLING BLOWER ASSEMBLY 2 BATTERY VOLTAGE SENSOR BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM ENGINE ROOM R/B 1 ENGINE ROOM R/B 2 FPO GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGCT 1 RELAY ENERGIZED HV SUPPLY BATTERY ASSEMBLY IGCT IGCT 1 FUSE IGCT FUSE IGCT RELAY 1 IGO LT GRN WIRE LUGGAGE ROOM R/B 1 ORG/ WIRE PNK WIRE PPL PPL/GRN WIRE RED WIRE SIO VIO WIRE WHT WIRE WHT/BLK WIRE
