Lexus RX V (2022-2024) vacuum regulating valve assembly Wiring diagrams
This page contains all the electrical diagrams for the component. vacuum regulating valve assembly, in which he is found in the car Lexus RX V (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram vacuum regulating valve assembly (1 of 2)
AIR FUEL RATIO SENSOR (BANK 1 SENSOR 1)
BLK WIRE
BLU WIRE
D INJ FUSE
D INJ RELAY
DIRECT FUEL INJECTOR ASSEMBLY 4
ECM (LEFT SIDE OF ENGINE COMPT)
EDU 1 FUSE
EDU 2 FUSE
EFCV
ENGINE ROOM R/B 1
EPEO
EPIM
EPR
FCA
FUEL PRESSURE SENSOR (HIGH PRESSURE SIDE)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT GRN WIRE
NCA WIRE
ORG/ WIRE
PEO
PIM
PNK WIRE
PPL/BLU WIRE
PPL/GRN WIRE
PPL/VIO WIRE
PPL/WHT WIRE
RED WIRE
THEO
THIM
VACUUM REGULATING VALVE ASSEMBLY
VCFV
VCPR
VCVG
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 2.4l turbo (5 of 8) -> VACUUM REGULATING VALVE ASSEMBLY
Wiring diagram vacuum regulating valve assembly (2 of 2)
+UM
BLK WIRE
BLPE
BLPU
BLPV
BLPW
BLU WIRE
BRN WIRE
CAM TIMING OIL CONTROL SOLENOID ASSEMBLY (EXHAUST SIDE)
CERTIFICATION ECU
DIRECT FUEL INJECTOR ASSEMBLY 1
DIRECT FUEL INJECTOR ASSEMBLY 2
DIRECT FUEL INJECTOR ASSEMBLY 3
DIRECT FUEL INJECTOR ASSEMBLY 4
EFCV
FCM+
FCV
FP-
FUEL MAIN VALVE ASSEMBLY
FUEL PUMP
FUEL PUMP ASSEMBLY (ENGINE ROOM SIDE)
GRN WIRE
GRY WIRE
IGPD
OIL PRESSURE SENDER
ORG/ WIRE
PNK WIRE
POUT
PPL/BLU WIRE
PPL/VIO WIRE
RED WIRE
RIGHT END OF DASH)
SHIELD
TEMPERATURE SENSOR
THEO
UL+
UN-
UP (+)
VACUUM REGULATING VALVE ASSEMBLY
VCFC
VIO WIRE
WATER CONTROL VALVE
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 2.5l turbo hybrid, engine controls circuit (4 of 8) -> VACUUM REGULATING VALVE ASSEMBLY
