Lexus RX V (2022-2024) meter-igr fuse Wiring diagrams

This page contains all the electrical diagrams for the component. meter-igr fuse, in which he is found in the car Lexus RX V (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram meter-igr fuse (31 of 37)

Wiring diagram meter-igr fuse for Lexus RX V (2022-2024) (31 of 37)

Get access

BLK WIRE COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM ECU-B 2 FUSE HOT AT ALL TIMES HOT W/ IGR 1 RELAY ENERGIZED LT BLU WIRE METER-IGR FUSE POWER DISTRIBUTION BOX ASSEMBLY PPL PPL EP PPL GND PPL/BLU WIRE PPL/RED WIRE PPL/WHT WIRE PPL/YEL WIRE RED WIRE SP- VEHICLE APPROACHING SPEAKER ASSEMBLY VEHICLE APPROACHING SPEAKER ASSEMBLY 2 VEHICLE APPROACHING SPEAKER CONTROLLER VIO WIRE WHT WIRE

Go to component -> Acoustic vehicle altering system circuit -> METER-IGR FUSE

Wiring diagram meter-igr fuse (32 of 37)

Wiring diagram meter-igr fuse for Lexus RX V (2022-2024) (32 of 37)

Get access

+BC ABS MTR 1 FUSE ABS- MAIN FUSE BLK WIRE BLU WIRE BRAKE BOOSTER CONTROL ECU (BRAKE BOOSTER W/ MASTER CYLINDER ASSEMBLY) BRAKE CONTROL POWER SUPPLY ASSEMBLY (UNDER REAR OF CENTER CONSOLE) BRAKE LEVEL WARNING SWITCH (BRAKE MASTER CYLINDER RESERVOIR ASSEMBLY) BRAKE PEDAL STROKE SENSOR ASSEMBLY (TOP OF BRAKE PEDAL ASSEMBLY) BRN WIRE CBKP CLIN COMPUTER DATA LINES SYSTEM CTY CWKP ECU-IGR 4 FUSE EFI 7/ ECU- IGP 2 FUSE ENGINE ROOM R/B 1 ENGINE ROOM R/B 2 GND SBIN LIN GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ EFI-MAIN 1 RELAY ENERGIZED HOT W/ IGR 1 RELAY ENERGIZED IGR INTEGRATION CONTROL SUPPLY LBL LEFT FRONT DOOR LOCK W/ MOTOR ASSEMBLY LT BLU WIRE LT GRN WIRE METER-IGR FUSE ORG/ WIRE OUT PNK DCTY WIRE PNK WIRE POWER DISTRIBUTION BOX ASSEMBLY PPL PPL/BLK WIRE PPL/GRN WIRE PPL/RED WIRE PPL/YEL WIRE RED WIRE SKG VCSK STOP FUSE VIO WIRE WHT WIRE WHT/BLK WIRE WKUP

Go to component -> Anti-lock brakes circuit (1 of 3) -> METER-IGR FUSE

Wiring diagram meter-igr fuse (33 of 37)

Wiring diagram meter-igr fuse for Lexus RX V (2022-2024) (33 of 37)

Get access

BLK WIRE BLU WIRE CFDH CFDL COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM ENGINE ROOM R/B 2 G/SHUTTER FUSE GRY WIRE HOT W/ EFI-MAIN 1 RELAY ENERGIZED HOT W/ IGR 1 RELAY ENERGIZED METER-IGR FUSE POWER DISTRIBUTION BOX ASSEMBLY PPL PPL EP RADIATOR SHUTTER ASSEMBLY RED WIRE VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Grille shutter circuit -> METER-IGR FUSE

Wiring diagram meter-igr fuse (34 of 37)

Wiring diagram meter-igr fuse for Lexus RX V (2022-2024) (34 of 37)

Get access

BLK WIRE BLU WIRE COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM DRS FUSE ECU-IGR 4 FUSE GNDY GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGR 1 RELAY ENERGIZED IGY LT GRN WIRE LUGGAGE ROOM R/B 1 METER-IGR FUSE POWER DISTRIBUTION BOX ASSEMBLY PPL PPL/BLK WIRE PPL/LT GRN WIRE REAR STEERING CONTROL ECU (REAR STEERING LINK ASSEMBLY) VIO WIRE WHT WIRE

Go to component -> Rear wheel steering circuit -> METER-IGR FUSE

Wiring diagram meter-igr fuse (35 of 37)

Wiring diagram meter-igr fuse for Lexus RX V (2022-2024) (35 of 37)

Get access

BLK WIRE BLU WIRE BRN WIRE ECM (LEFT SIDE OF ENGINE COMPT) ECU-IGR 1 FUSE EGA+ EGB- ENGINE ROOM R/B 1 FUEL OPN FUSE FUEL OPN RELAY GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGR 1 RELAY ENERGIZED METER-IGR FUSE PNK WIRE POWER DISTRIBUTION BOX ASSEMBLY PPL PPL/BLK WIRE PPL/BLU WIRE PPL/GRN WIRE PPL/RED WIRE PPL/VIO WIRE PPL/WHT WIRE RED WIRE VIO WIRE VOP VVT FUSE VVT RELAY WHT WIRE WHT/BLK WIRE WPI WPO

Go to component -> Wiring diagram engine performance 2.5l turbo hybrid, engine controls circuit (3 of 7) -> METER-IGR FUSE

Wiring diagram meter-igr fuse (36 of 37)

Wiring diagram meter-igr fuse for Lexus RX V (2022-2024) (36 of 37)

Get access

BLK WIRE BLU WIRE BRN WIRE CCA- CCB- ECM (LEFT SIDE OF ENGINE COMPT) ECU-IGR 2 FUSE EDU 1 FUSE EDU 2 FUSE ENGINE ROOM R/B 1 FAN W/ MOTOR ASSEMBLY FCM+ FUEL OPN 1 FUSE FUEL OPN RELAY GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGR 1 RELAY ENERGIZED HOT W/ IGR 2 RELAY ENERGIZED IGP 1 RELAY IGP- MAIN 1 FUSE IWPI IWPO LT BLU WIRE LT GRN WIRE METER-IGR FUSE PNK WIRE POWER DISTRIBUTION BOX ASSEMBLY PPL PPL/BLU WIRE PPL/GRN WIRE PPL/VIO WIRE RED WIRE RFC VIO WIRE WGV+ WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Wiring diagram engine performance 2.5l turbo hybrid, engine controls circuit (3 of 8) -> METER-IGR FUSE

Wiring diagram meter-igr fuse (37 of 37)

Wiring diagram meter-igr fuse for Lexus RX V (2022-2024) (37 of 37)

Get access

AIR BAG ECU ASSEMBLY BATT FAN 1 FUSE BATT FAN 1 RELAY BATT FAN 2 FUSE BATT FAN FUSE BATTERY COOLING BLOWER ASSEMBLY BATTERY COOLING BLOWER ASSEMBLY 2 BLK WIRE BLU WIRE BRN WIRE COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM ECU-B 2 FUSE ECU-IGR 1 FUSE GRN WIRE HOT AT ALL TIMES HOT W/ IGR 1 RELAY ENERGIZED LT BLU WIRE LT GRN WIRE LUGGAGE ROOM R/B 1 METER-IGR FUSE ORG/ WIRE ORG/BLU WIRE ORG/LT GRN WIRE POWER DISTRIBUTION BOX ASSEMBLY PPL PPL/BLK WIRE PPL/BLU WIRE PPL/WHT WIRE RED WIRE VIO WIRE WHT WIRE WHT/BLK WIRE

Go to component -> Wiring diagram engine performance 2.5l turbo hybrid, hybrid system circuit (6 of 7) -> METER-IGR FUSE
