Lexus RX V (2022-2024) combination meter assembly Wiring diagrams

This page contains all the electrical diagrams for the component. combination meter assembly, in which he is found in the car Lexus RX V (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

combination meter assembly wiring diagram (41 of 50)

BLK WIRE COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM ECU-B 2 FUSE HOT AT ALL TIMES HOT W/ IGR 1 RELAY ENERGIZED LT BLU WIRE METER-IGR FUSE POWER DISTRIBUTION BOX ASSEMBLY PPL PPL EP PPL GND PPL/BLU WIRE PPL/RED WIRE PPL/WHT WIRE PPL/YEL WIRE RED WIRE SP- VEHICLE APPROACHING SPEAKER ASSEMBLY VEHICLE APPROACHING SPEAKER ASSEMBLY 2 VEHICLE APPROACHING SPEAKER CONTROLLER VIO WIRE WHT WIRE

Go to component -> Acoustic vehicle altering system circuit -> COMBINATION METER ASSEMBLY

combination meter assembly wiring diagram (42 of 50)

2.4L TURBO HYBRID 2.5L TURBO HYBRID ABS 2 FUSE ABS 3 FUSE ABS MTR 2 FUSE BLK WIRE BLU WIRE CAN L COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM ECU- IGP 2 FUSE ECU-IGP 3 FUSE ENGINE ROOM R/B 1 ENGINE ROOM R/B 2 EPB GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGP 1 RELAY ENERGIZED HYBRID VEHICLE CONTROL ECU (LEFT END OF DASH) IG+ EP LEFT FRONT SPEED SENSOR LEFT PARKING BRAKE ACTUATOR ASSEMBLY LEFT REAR SKID CONTROL SENSOR LT GRN WIRE PNK WIRE PPL PPL/BLU WIRE PPL/GRN WIRE PPL/RED WIRE PPL/YEL WIRE RED WIRE VIO WIRE W/O ADAPTIVE VARIABLE SUSPENSION WHT WIRE WSS- WSS+

Go to component -> Anti-lock brakes circuit (2 of 3) -> COMBINATION METER ASSEMBLY

combination meter assembly wiring diagram (43 of 50)

BLK WIRE BLU WIRE CAN JUNCTION TERMINAL 4 COMBINATION METER ASSEMBLY DRIVER MONITOR ECU ASSEMBLY ET+ ETH (-) GRN WIRE INNER REAR VIEW MIRROR ASSEMBLY MOBILE WIRELESS CHARGER CRADLE ASSEMBLY PNK WIRE PPL RADIO, DISPLAY RECEIVER ASSEMBLY RED WIRE STEREO COMPONENT EQUALIZER ASSEMBLY STEREO COMPONENT EQUALIZER ASSEMBLY 2 VIO WIRE WHT WIRE YEL WIRE

Go to component -> Computer data lines circuit (8 of 8) -> COMBINATION METER ASSEMBLY

combination meter assembly wiring diagram (44 of 50)

BLK WIRE BLU WIRE CFDH CFDL COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM ENGINE ROOM R/B 2 G/SHUTTER FUSE GRY WIRE HOT W/ EFI-MAIN 1 RELAY ENERGIZED HOT W/ IGR 1 RELAY ENERGIZED METER-IGR FUSE POWER DISTRIBUTION BOX ASSEMBLY PPL PPL EP RADIATOR SHUTTER ASSEMBLY RED WIRE VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Grille shutter circuit -> COMBINATION METER ASSEMBLY

combination meter assembly wiring diagram (45 of 50)

BLK WIRE BLU WIRE COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM DRS FUSE ECU-IGR 4 FUSE GNDY GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGR 1 RELAY ENERGIZED IGY LT GRN WIRE LUGGAGE ROOM R/B 1 METER-IGR FUSE POWER DISTRIBUTION BOX ASSEMBLY PPL PPL/BLK WIRE PPL/LT GRN WIRE REAR STEERING CONTROL ECU (REAR STEERING LINK ASSEMBLY) VIO WIRE WHT WIRE

Go to component -> Rear wheel steering circuit -> COMBINATION METER ASSEMBLY

combination meter assembly wiring diagram (46 of 50)

BLK WIRE BLU WIRE BRN WIRE COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM ECU-IGR 1 FUSE ENGINE ROOM R/B 1 ENGINE ROOM R/B 2 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGCT 1 RELAY ENERGIZED HOT W/ IGCT 2 RELAY ENERGIZED HOT W/ IGR 1 RELAY ENERGIZED IGCT 3 FUSE LT GRN WIRE METER-IGR FUSE OIL PMP FUSE OIL PMP RELAY PCU RR FUSE PNK WIRE POWER DISTRIBUTION BOX ASSEMBLY PPL PPL/BLK WIRE PPL/BLU WIRE PPL/GRN WIRE PPL/RED WIRE PPL/WHT WIRE RED WIRE STOP FUSE STOP LIGHT SWITCH ASSEMBLY (TOP OF BRAKE PEDAL ASSEMBLY) VIO WIRE WHT WIRE WHT/BLK WIRE

Go to component -> Transmission circuit (4 of 4) -> COMBINATION METER ASSEMBLY

combination meter assembly wiring diagram (47 of 50)

AIR FUEL RATIO SENSOR 2 (BANK 1 SENSOR 2) BLK WIRE BLPE BLPU BLPV BLPW BLU WIRE BRN WIRE CAMSHAFT POSITION SENSOR (EXHAUST SIDE) COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM CRANK POSITION SENSOR ECM (LEFT SIDE OF ENGINE COMPT) EPFL EPTA FPC FPG FPU FPV FPW FUEL PRESSURE SENSOR (LOW PRESSURE SIDE) FUEL PUMP FUEL PUMP CONTROL ECU GRN WIRE GRY WIRE LT BLU WIRE LT GRN WIRE NCA WIRE NE+ PFL PNK WIRE PPL PPL/BLU WIRE PPL/GRN WIRE PPL/VIO WIRE PPL/WHT WIRE PTA RED WIRE TMK MADE TMMC MADE VCNE VCPE VCPF VCPM VIO WIRE VPTA VVE- WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Wiring diagram engine performance 2.4l turbo (3 of 8) -> COMBINATION METER ASSEMBLY

combination meter assembly wiring diagram (48 of 50)

BLK WIRE BLU WIRE CAMSHAFT POSITION SENSOR (INTAKE SIDE) COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM ECM (LEFT SIDE OF ENGINE COMPT) ENGINE ROOM R/B 1 EPFL GRN WIRE GRY WIRE HOT W/ IGP 1 RELAY ENERGIZED IGNITION COIL ASSEMBLY 1 IGNITION COIL ASSEMBLY 2 IGNITION COIL ASSEMBLY 3 IGNITION COIL ASSEMBLY 4 INJ FUSE LT GRN WIRE PNK WIRE PPL PPL/BLK WIRE PPL/BLU WIRE RED WIRE VCPF VCVG VIO WIRE VVI+ WHT WIRE WHT/BLK WIRE

Go to component -> Wiring diagram engine performance 2.5l turbo hybrid, engine controls circuit (5 of 7) -> COMBINATION METER ASSEMBLY

combination meter assembly wiring diagram (49 of 50)

BLK WIRE BLU WIRE BRN WIRE COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM ECM (LEFT SIDE OF ENGINE COMPT) ECU- IGP 1 FUSE EFI 2 FUSE EFI 8 FUSE ENGINE ROOM R/B 2 FREL GRN WIRE GRY WIRE INV W/ PMP 1 FUSE OCV- OIL PRESSURE CONTROL VALVE ASSEMBLY PNK WIRE PPL PPL/BLU WIRE PPL/GRN WIRE PPL/LT BLU WIRE PPL/PNK WIRE PPL/RED WIRE PPL/VIO WIRE RED WIRE VACUUM SWITCHING VALVE ASSEMBLY 1 VIO WIRE VOP WHT WIRE

Go to component -> Wiring diagram engine performance 2.5l turbo hybrid, engine controls circuit (7 of 8) -> COMBINATION METER ASSEMBLY

combination meter assembly wiring diagram (50 of 50)

AIR BAG ECU ASSEMBLY BATT FAN 1 FUSE BATT FAN 1 RELAY BATT FAN 2 FUSE BATT FAN FUSE BATTERY COOLING BLOWER ASSEMBLY BATTERY COOLING BLOWER ASSEMBLY 2 BLK WIRE BLU WIRE BRN WIRE COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM ECU-B 2 FUSE ECU-IGR 1 FUSE GRN WIRE HOT AT ALL TIMES HOT W/ IGR 1 RELAY ENERGIZED LT BLU WIRE LT GRN WIRE LUGGAGE ROOM R/B 1 METER-IGR FUSE ORG/ WIRE ORG/BLU WIRE ORG/LT GRN WIRE POWER DISTRIBUTION BOX ASSEMBLY PPL PPL/BLK WIRE PPL/BLU WIRE PPL/WHT WIRE RED WIRE VIO WIRE WHT WIRE WHT/BLK WIRE

Go to component -> Wiring diagram engine performance 2.5l turbo hybrid, hybrid system circuit (6 of 7) -> COMBINATION METER ASSEMBLY
