Car Wiring Diagrams for Climate control seats circuit for Lexus RX IV facelift (2019-2023)

A/C AMPLIFIER ASSEMBLY BLK WIRE BLU WIRE ECU-B 2 FUSE ENGINE ROOM R/B FRONT REFRESHING SEAT SWITCH FRONT SEAT BLOWER SWITCH GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGNITION 1 RELAY ENERGIZED INSTRUMENT PANEL J/B ASSEMBLY LEFT FRONT SEAT HEATER CONTROL SUB-ASSEMBLY LEFT SEAT BACK CLIMATE CONTROL BLOWER LEFT SEAT CUSHION CLIMATE CONTROL BLOWER ASSEMBLY LOUT LT BLU WIRE LT GRN WIRE ORG/ WIRE PNK WIRE RED WIRE RELAY ENERGIZED RIGHT FRONT SEAT HEATER CONTROL SUB-ASSEMBLY RIGHT SEAT BACK CLIMATE CONTROL BLOWER RIGHT SEAT CUSHION CLIMATE CONTROL BLOWER ASSEMBLY ROUT S/HTR F/L FUSE S/HTR F/R FUSE SG-5 SHP+ SWR THR+ TSL PNK SHD+ WIRE TSR PNK SG-6 WIRE VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
