Lexus RX IV facelift (2019-2023) yaw rate sensor assembly Wiring diagrams
This page contains all the electrical diagrams for the component. yaw rate sensor assembly, in which he is found in the car Lexus RX IV facelift (2019-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram yaw rate sensor assembly (1 of 9)
BLK WIRE
BLU WIRE
BSF
CAN I/F
COMBINATION METER ASSEMBLY
COMBINATION SWITCH ASSEMBLY
COMPUTER DATA LINES SYSTEM
DISPLAY DRIVER
ELECTRO MAGNETIC CONTROL COUPLING SUB-ASSEMBLY
ENGINE ROOM R/B
GRN WIRE
GRY WIRE
INSTRUMENT PANEL J/B ASSEMBLY
LED DRIVER
LOCK
MAIN RELAY ENERGIZED
PNK WIRE
RED WIRE
RELAY ENERGIZED
RIGHT END OF DASH)
SLC+
STEERING SENSOR
TELLTALES
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YAW RATE SENSOR ASSEMBLY
Go to component -> 4wd circuit -> YAW RATE SENSOR ASSEMBLY
Wiring diagram yaw rate sensor assembly (2 of 9)
BLK WIRE
BLU WIRE
COMBINATION SWITCH ASSEMBLY
COMPUTER DATA LINES SYSTEM
FORWARD RECOGNITION CAMERA
GRN WIRE
GRY WIRE
INSTRUMENT PANEL J/B ASSEMBLY
LEFT REAR SPEED SENSOR
LT GRN WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
RELAY ENERGIZED
SKID CONTROL BUZZER ASSEMBLY
VIO WIRE
VSC OFF SWITCH
W/O ADAPTIVE VARIABLE SUSPENSION
WHT WIRE
WHT/BLK WIRE
YAW RATE SENSOR ASSEMBLY
YEL WIRE
Go to component -> Anti-lock brakes circuit (3 of 5) -> YAW RATE SENSOR ASSEMBLY
Wiring diagram yaw rate sensor assembly (3 of 9)
BLK WIRE
BLU WIRE
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DRIVER DISPLAY
GRY WIRE
LEFT REAR SHOCK ABSORBER ASSEMBLY
LEFT REAR SPEED SENSOR
LT GRN WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
SPEAKER
VIO WIRE
W/O ADAPTIVE VARIABLE SUSPENSION
WHT WIRE
WHT/BLK WIRE
YAW RATE SENSOR ASSEMBLY
YEL WIRE
Go to component -> Anti-lock brakes circuit (4 of 4) -> YAW RATE SENSOR ASSEMBLY
Wiring diagram yaw rate sensor assembly (4 of 9)
ABSORBER CONTROL ECU
ACL
AIR BAG SENSOR ASSEMBLY
BLK WIRE
BLU WIRE
BRAKE ACTUATOR ASSEMBLY
CAN JUNCTION TERMINAL 1 (UNDER CENTER CONSOLE)
CANN
CANP
CLOCK ASSEMBLY
GRN WIRE
GRY WIRE
LT BLU WIRE
LT GRN WIRE
OCCUPANT DETECTION ECU
PNK WIRE
POWER STEERING ECU ASSEMBLY
RED WIRE
RIGHT END OF DASH)
RIGHT OUTER MIRROR CONTROL ECU ASSEMBLY
STEERING SENSOR (TOP OF STEERING COLUMN)
TX+1
TX-1
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YAW RATE SENSOR ASSEMBLY
YEL WIRE
Go to component -> Computer data lines circuit (4 of 4) -> YAW RATE SENSOR ASSEMBLY
Wiring diagram yaw rate sensor assembly (5 of 9)
ABSORBER CONTROL ECU
ACL
AIR BAG SENSOR ASSEMBLY
BLK WIRE
BLU WIRE
CAN (+)
CAN JUNCTION TERMINAL 1 (LOWER LEFT CENTER OF DASH)
CANN
CANP
GRN WIRE
GRY WIRE
HYBRID VEHICLE CONTROL ECU
LT BLU WIRE
LT GRN WIRE
OCCUPANT DETECTION ECU
PARKING BRAKE ECU ASSEMBLY
PNK WIRE
POWER STEERING ECU ASSEMBLY
RED WIRE
RIGHT END OF DASH)
RIGHT OUTER MIRROR CONTROL ECU ASSEMBLY
SKID CONTROL ECU ASSEMBLY
STEERING SENSOR (IN STEERING COLUMN)
VEHICLE APPROACHING SPEAKER CONTROLLER
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YAW RATE SENSOR ASSEMBLY
YEL WIRE
Go to component -> Computer data lines circuit (5 of 5) -> YAW RATE SENSOR ASSEMBLY
Wiring diagram yaw rate sensor assembly (6 of 9)
A/C AMPLIFIER ASSEMBLY
ACC RELAY
AIR BAG SENSOR ASSEMBLY
ALL DR LOCK RELAY
BKUP LP RELAY
BLK WIRE
BLK/WHT WIRE
BRN WIRE
CAN JUNCTION TERMINAL 2
COMBINATION METER ASSEMBLY
CRUISE CONTROL MAIN SWITCH
D DR UNLOCK RELAY
ELECTRIC PARKING BRAKE SWITCH ASSEMBLY
FRONT REFRESHING SEAT SWITCH
HEADLIGHT DIMMER SWITCH ASSEMBLY
HYBRID VEHICLE CONTROL ECU
INSTRUMENT PANEL J/B ASSEMBLY
INTEGRATION CONTROL, PANEL ASSEMBLY
L/D-DR UNLOCK RELAY
LEFT VISOR ASSEMBLY
MAIN BODY ECU
MAP LIGHT ASSEMBLY
METER MIRROR SUB-ASSEMBLY
MULTIPLEX TILT, TELESCOPIC ECU
P/OUTLET 2 RELAY
POWER OUTLET SOCKET ASSEMBLY 1
POWER STEERING ECU ASSEMBLY
R/B 4
RIGHT STEERING PAD SWITCH
RIGHT VISOR ASSEMBLY
ROOF SUNSHADE ECU (SLIDING ROOF DRIVE GEAR ASSEMBLY)
SHIFT LOCK CONTROL ECU (TRANSMISSION FLOOR SHIFT ASSEMBLY)
SLIDING ROOF CONTROL ECU (SLIDING ROOF DRIVE GEAR ASSEMBLY)
SPIRAL CABLE SUB-ASSEMBLY
STEERING LOCK ACTUATOR/ UPPER BRACKET ASSEMBLY
STEERING PAD SWITCH ASSEMBLY
STEERING VIBRATION, HEATER ECU
STEREO COMPONENT AMPLIFIER ASSEMBLY
SWITCH WIRE 1
USB CHARGER SOCKET
USB CHARGER SOCKET 2
W/ PANORAMIC MOON ROOF SYSTEM
WHT/BLK WIRE
WINDSHIELD WIPER SWITCH ASSEMBLY
YAW RATE SENSOR ASSEMBLY
Go to component -> Ground distribution circuit (3 of 6) -> YAW RATE SENSOR ASSEMBLY
Wiring diagram yaw rate sensor assembly (7 of 9)
A/C AMPLIFIER ASSEMBLY
ACC RELAY
AIR BAG SENSOR ASSEMBLY
ALL DR LOCK RELAY
BKUP LP RELAY
BLK WIRE
BRN WIRE
CAN JUNCTION TERMINAL 2
COMBINATION METER ASSEMBLY
D DR UNLOCK RELAY
ELECTRIC PARKING BRAKE SWITCH ASSEMBLY
FRONT REFRESHING SEAT SWITCH
FUEL LOCK RELAY
HEADLIGHT DIMMER SWITCH ASSEMBLY
INSTRUMENT PANEL J/B ASSEMBLY
INTEGRATION CONTROL, PANEL ASSEMBLY
L/D-DR UNLOCK RELAY
LEFT VISOR ASSEMBLY
MAIN BODY ECU
MAP LIGHT ASSEMBLY
METER MIRROR SUB-ASSEMBLY
MULTIPLEX TILT, TELESCOPIC ECU
P/OUTLET 2 RELAY
POWER OUTLET SOCKET ASSEMBLY 1
POWER STEERING ECU ASSEMBLY
R/B 4
RIGHT VISOR ASSEMBLY
ROOF SUNSHADE ECU (SLIDING ROOF DRIVE GEAR ASSEMBLY)
SHIFT LOCK CONTROL ECU (TRANSMISSION FLOOR SHIFT ASSEMBLY)
SHIFT POSITION INDICATOR
SLIDING ROOF CONTROL ECU (SLIDING ROOF DRIVE GEAR ASSEMBLY)
SPIRAL CABLE SUB-ASSEMBLY
STEERING LOCK ACTUATOR/ UPPER BRACKET ASSEMBLY
STEERING VIBRATION, HEATER ECU
STEREO COMPONENT AMPLIFIER ASSEMBLY
USB CHARGER SOCKET 2
USB CHARGER SOCKET 3
W/ PANORAMIC MOON ROOF SYSTEM
W/ SLIDING ROOF
WHT/BLK WIRE
WINDSHIELD WIPER SWITCH ASSEMBLY
YAW RATE SENSOR ASSEMBLY
Go to component -> Ground distribution circuit (3 of 7) -> YAW RATE SENSOR ASSEMBLY
Wiring diagram yaw rate sensor assembly (8 of 9)
A/F FUSE
A/F RELAY
ABSORBER CONTROL ECU
AVS FUSE
BLK WIRE
BLU WIRE
BRN WIRE
EFI MAIN FUSE
EFI MAIN RELAY
ENGINE ROOM R/B
FAN 1 RELAY
FAN 2 RELAY
FOR PORT INJECTION
FROM DC/DC FUSE (DIAGRAM 1 OF 10)
FROM ENGINE ROOM R/B (DIAGRAM 3 OF 10)
FROM INSTRUMENT PANEL J/B ASSEMBLY (DIAGRAM 5 OF 10)
FUEL INJECTOR ASSEMBLY 1
FUEL INJECTOR ASSEMBLY 2
FUEL INJECTOR ASSEMBLY 3
FUEL INJECTOR ASSEMBLY 4
FUEL INJECTOR ASSEMBLY 5
FUEL INJECTOR ASSEMBLY 6
GRN WIRE
GRY WIRE
H-LP LH LO FUSE
H-LP LH-LO RELAY
H-LP RH LO FUSE
H-LP RH-LO RELAY
HYBRID VEHICLE CONTROL ECU
IGNITION COIL ASSEMBLY 1
IGNITION COIL ASSEMBLY 2
IGNITION COIL ASSEMBLY 3
IGNITION COIL ASSEMBLY 4
IGNITION COIL ASSEMBLY 5
IGNITION COIL ASSEMBLY 6
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
P INJ FUSE
PNK WIRE
RED WIRE
SHIFT LOCK CONTROL ECU
SKID CONTROL ECU ASSEMBLY
SPIRAL CABLE SUB-ASSEMBLY
STEERING LOCK ACTUATOR OR UPPER BRACKET ASSEMBLY
STEERING SENSOR
STEERING VIBRATION, HEATER ECU
STRG HTR FUSE
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YAW RATE SENSOR ASSEMBLY
YEL WIRE
Go to component -> Power distribution circuit (4 of 10) -> YAW RATE SENSOR ASSEMBLY
Wiring diagram yaw rate sensor assembly (9 of 9)
A/F FUSE
A/F RELAY
ABSORBER CONTROL ECU
AVS FUSE
BLK WIRE
BLU WIRE
BRAKE ACTUATOR ASSEMBLY
BRN WIRE
EFI MAIN FUSE
EFI MAIN RELAY
ENGINE ROOM R/B
FAN RELAY ENGINE ROOM R/B
FROM ALT FUSE (DIAGRAM 1 OF 9)
FROM ENGINE ROOM R/B (DIAGRAM 3 OF 9)
FROM INSTRUMENT PANEL J/B ASSEMBLY (DIAGRAM 5 OF 9)
FUEL INJECTOR ASSEMBLY 1 (FOR PORT INJECTION)
FUEL INJECTOR ASSEMBLY 2 (FOR PORT INJECTION)
FUEL INJECTOR ASSEMBLY 3 (FOR PORT INJECTION)
FUEL INJECTOR ASSEMBLY 4 (FOR PORT INJECTION)
FUEL INJECTOR ASSEMBLY 5 (FOR PORT INJECTION)
FUEL INJECTOR ASSEMBLY 6 (FOR PORT INJECTION)
GRN WIRE
GRY WIRE
H-LP LH LO FUSE
H-LP LH-LO RELAY
H-LP RH LO FUSE
H-LP RH-LO RELAY
IGNITION COIL ASSEMBLY 1
IGNITION COIL ASSEMBLY 2
IGNITION COIL ASSEMBLY 3
IGNITION COIL ASSEMBLY 4
IGNITION COIL ASSEMBLY 5
IGNITION COIL ASSEMBLY 6
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
P INJ FUSE
PNK WIRE
RED WIRE
SHIFT LOCK CONTROL ECU (TRANSMISSION FLOOR SHIFT ASSEMBLY)
SPIRAL CABLE SUB-ASSEMBLY
STEERING LOCK ACTUATOR/ UPPER BRACKET ASSEMBLY
STEERING SENSOR
STEERING VIBRATION, HEATER ECU
STRG HTR FUSE
VIO WIRE
W/O HEADLIGHT BEAM LEVEL CONTROL
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YAW RATE SENSOR ASSEMBLY
YEL WIRE
Go to component -> Power distribution circuit (4 of 9) -> YAW RATE SENSOR ASSEMBLY
