Lexus RX IV facelift (2019-2023) semiconductor power integration ecu engine room j/b Wiring diagrams
This page contains all the electrical diagrams for the component. semiconductor power integration ecu engine room j/b, in which he is found in the car Lexus RX IV facelift (2019-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram semiconductor power integration ecu engine room j/b (1 of 2)
ACC RELAY
BLK WIRE
BLU WIRE
DOOR BACK FUSE
DOOR BACK RELAY
DOOR F/L FUSE
DOOR F/R FUSE
DOOR R/L FUSE
DOOR R/R FUSE
ECU-ACC FUSE
FROM ENGINE ROOM J/B (DIAGRAM 1 OF 9)
GRN WIRE
GRY WIRE
LEFT FRONT POWER SEAT SWITCH
LEFT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY
LEFT HEADLIGHT ASSEMBLY
LEFT OUTER MIRROR CONTROL ECU ASSEMBLY
LEFT POSITION CONTROL ECU, SWITCH ASSEMBLY
LEFT REAR COMBINATION LIGHT ASSEMBLY
LEFT REAR LIGHT ASSEMBLY
LEFT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY
LEFT SEAT MEMORY SWITCH
LEFT SEAT VARIABLE CUSHION SWITCH
LT BLU WIRE
MAIN BODY ECU
MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY
MULTIPLEX TILT, TELESCOPIC ECU
P/ OUTLET 1 FUSE
P/SEAT (FR) FUSE
P/SEAT F/L FUSE
PANEL FUSE
PNK WIRE
POWER OUTLET SOCKET ASSEMBLY 1
PPL
PPL/GRN WIRE
PPL/GRY WIRE
PPL/PNK WIRE
RED WIRE
RIGHT FRONT POWER SEAT SWITCH
RIGHT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY
RIGHT HEADLIGHT ASSEMBLY
RIGHT LICENSE PLATE LIGHT ASSEMBLY
RIGHT OUTER MIRROR CONTROL ECU ASSEMBLY
RIGHT REAR COMBINATION LIGHT ASSEMBLY
RIGHT REAR LIGHT ASSEMBLY
RIGHT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY
RIGHT SEAT VARIABLE CUSHION SWITCH
S/ROOF FUSE
SEMICONDUCTOR POWER INTEGRATION ECU ENGINE ROOM J/B
SLIDING ROOF CONTROL ECU (SLIDING ROOF DRIVE GEAR ASSEMBLY)
TAIL FUSE
TAIL RELAY
TI, TE FUSE
TO DOME FUSE (DIAGRAM 8 OF 9)
TOWING CONVERTER
USED)
VIO WIRE
W/ HEADLIGHT BEAM LEVEL CONTROL
W/ LED
W/ MEMORY
W/ SEAT VARIABLE CUSHION
W/O HEADLIGHT BEAM LEVEL CONTROL
W/O LED
W/O MEMORY
W/O SEAT VARIABLE CUSHION
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power distribution circuit (6 of 9) -> SEMICONDUCTOR POWER INTEGRATION ECU ENGINE ROOM J/B
Wiring diagram semiconductor power integration ecu engine room j/b (2 of 2)
A/C AMPLIFIER ASSEMBLY
AMP FUSE
BKUP LP FUSE
BKUP LP RELAY
BLK WIRE
BLU WIRE
BRN WIRE
COMPRESSOR W/ MOTOR ASSEMBLY
ENGINE ROOM R/B
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
ETCS FUSE
FMIG
FORWARD RECOGNITION CAMERA
FORWARD RECOGNITION W/ HEATER HOOD SUB-ASSEMBLY
FROM ABS MTR 1 FUSE (DIAGRAM 1 OF 10)
FRONT REFRESHING SEAT SWITCH
FUEL OPN FUSE
FUEL OPN RELAY
FUEL PMP FUSE
FUEL PMP RELAY
GRN WIRE
GRY WIRE
H-LP CLN RELAY
H-LP LH FUSE
H-LP LH RELAY
H-LP RH FUSE
H-LP RH RELAY
HORN FUSE
HORN RELAY
IGCT FUSE
IGCT RELAY ENGINE ROOM R/B 2
INJ FUSE
INJ RELAY ENGINE ROOM R/B
INSTRUMENT PANEL J/B ASSEMBLY
INTEGRATION CONTROL, PANEL ASSEMBLY
LT BLU WIRE
LT GRN WIRE
MILLIMETER WAVE RADAR SENSOR ASSEMBLY
PNK WIRE
PTC HTR 1 RELAY
PTC HTR 2 RELAY
PTC HTR 3 RELAY
RADIO 2 FUSE
RED WIRE
S-HORN FUSE
S-HORN RELAY
SEMICONDUCTOR POWER INTEGRATION ECU ENGINE ROOM J/B
SKID CONTROL BUZZER ASSEMBLY
SMOG VENTILATION SENSOR
STEREO COMPONENT AMPLIFIER ASSEMBLY
TO D/C CUT FUSE (DIAGRAM 2 OF 10)
TO R/B 4 (DIAGRAM 3 OF 10)
TOWING CONVERTER
TOWING FUSE
USED)
VIO WIRE
W/ HEADLIGHT BEAM LEVEL CONTROL
W/O PRE-COLLISION SYSTEM HEATER
WHT WIRE
WIPER FUSE
WIPER RELAY
YEL WIRE
Go to component -> Power distribution circuit (7 of 10) -> SEMICONDUCTOR POWER INTEGRATION ECU ENGINE ROOM J/B
