Lexus RX IV facelift (2019-2023) selectable force limiter Wiring diagram
This page shows the only wiring diagram for the component.selectable force limiter, which is found in the car Lexus RX IV facelift (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram selectable force limiter (1 of 1)
AIR
AIR BAG SENSOR ASSEMBLY
ARON
BBR+
BLK WIRE
BLU WIRE
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DISPLAY
FCP+
FCP- FCP+
GRN WIRE
GRY WIRE
ICR+
INSTRUMENT PANEL J/B ASSEMBLY
LED
PASSENGER AIR BAG ON/OFF INDICATOR
PASSIVE RESTRAINTS SYSTEM
PNK WIRE
PR-
PRETENSIONER
PRETENSIONER RIGHT REAR SEAT OUTER BELT ASSEMBLY 1
PRR-
RADIO RECEIVER ASSEMBLY
RELAY ENERGIZED
RIGHT CURTAIN SHIELD AIR BAG ASSEMBLY
RIGHT FRONT SEAT AIR BAG ASSEMBLY
RIGHT FRONT SEAT CUSHION AIR BAG ASSEMBLY
RIGHT FRONT SEAT OUTER BELT ASSEMBLY (BASE OF RIGHT "B" PILLAR)
RR- RR+
SELECTABLE FORCE LIMITER
SFR-
SPEAKER
SR-
SRR+
TELLTALES
TMK MADE
VIO WIRE
W/ NAVIGATION SYSTEM
W/O NAVIGATION SYSTEM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Supplemental restraints circuit (3 of 3) -> SELECTABLE FORCE LIMITER
