Car Wiring Diagrams for Immobilizer circuit for Lexus RX IV (2015-2019)

BLK WIRE BLU WIRE CERTIFICATION ECU COMPUTER DATA LINES SYSTEM ECU-B 3 FUSE HOT AT ALL TIMES HYBRID VEHICLE CONTROL ECU ID CODE BOX INSTRUMENT PANEL J/B ASSEMBLY LT GRN WIRE RED WIRE STEERING LOCK ACTUATOR (ON STEERING COLUMN) STEERING LOCK ACTUATOR/ UPPER BRACKET ASSEMBLY WHT WIRE WHT/BLK WIRE
