Lexus RX IV (2015-2019) wiper deicer switch wiring diagram
This page shows the only wiring diagram for the component.wiper deicer switch, which is found in the car Lexus RX IV (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
wiper deicer switch wiring diagram (1 of 1)
A/C AMPLIFIER ASSEMBLY
ALT
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
DC/DC FUSE
ENGINE ROOM J/B
FDEF
FMIG
FRONT WIPER DEICER (WINDSHIELD GLASS)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/
INSTRUMENT PANEL J/B ASSEMBLY
LT GRN WIRE
ORG/ WIRE
RADIO RECEIVER ASSEMBLY
SEMICONDUCTOR POWER INTEGRATION ECU
WHT WIRE
WHT/BLK WIRE
WIPER DEICER SWITCH
Go to component -> Front deicer circuit -> WIPER DEICER SWITCH
