Lexus RX IV (2015-2019) power back door switch Wiring diagram
This page shows the only wiring diagram for the component.power back door switch, which is found in the car Lexus RX IV (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power back door switch (1 of 1)
BACK DOOR LOCK ASSEMBLY
BACK DOOR OPENER SWITCH ASSEMBLY
BLK WIRE
BLU WIRE
CERTIFICATION ECU
CLS
COMPUTER DATA LINES SYSTEM
CSEL
CTY
DATA
DOOR CONTROL SWITCH
FSW+
GRN WIRE
GRY WIRE
INTEGRATION CONTROL, PANEL ASSEMBLY
LEFT POWER BACK DOOR SENSOR ASSEMBLY
LOCK
LT BLU WIRE
LT GRN WIRE
OPN
PNK WIRE
POWER BACK DOOR SWITCH
POWER BACK DOOR WARNING BUZZER
RCO
RDAM
RED WIRE
RIGHT POWER BACK DOOR SENSOR ASSEMBLY
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Back door opener circuit (2 of 2) -> POWER BACK DOOR SWITCH
