Lexus RX IV (2015-2019) pnk illb Wiring diagrams
This page contains all the electrical diagrams for the component. pnk illb, in which he is found in the car Lexus RX IV (2015-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram pnk illb (1 of 2)
BLK WIRE
BLU WIRE
CILL
CTY
DOME LIGHT
DOOR
GRN WIRE
GRY WIRE
INSTRUMENT ILLUMINATION CIRCUIT
LEFT FRONT
LEFT SPOT LIGHT
LEFT VANITY LIGHT ASSEMBLY
LEFT VISOR ASSEMBLY
LENS
MAIN BOARD
MAP LIGHT
MAP LIGHT ASSEMBLY
MICRO COMPUTER
ORG/ WIRE
PNK ILLB WIRE
PNK WIRE
POWER SUPPLY CIRCUIT
RED WIRE
RIFL
RIFR
RIGHT FRONT
RIGHT SPOT LIGHT
RIGHT VANITY LIGHT ASSEMBLY
RIGHT VISOR ASSEMBLY
RLMP
SPOT LIGHT ASSEMBLY
TOUCH -
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Courtesy lamps circuit (4 of 4) -> PNK ILLB WIRE
Wiring diagram pnk illb (2 of 2)
ACAN
AUTO
BLK WIRE
BLU WIRE
CERTIFICATION ECU (RIGHT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
DCM (TELEMATICS TRANSCEIVER)
DRL OFF OFF
ECU-ACC FUSE
ECU-B 4 FUSE
ENGINE ROOM R/B
FUSE BLOCK ASSEMBLY 2
GRN WIRE
GRY WIRE
HEAD
HEADLIGHT DIMMER SWITCH ASSEMBLY
HOT AT ALL TIMES
HOT W/ ACC RELAY ENERGIZED
ILLB
INSTRUMENT PANEL J/B ASSEMBLY
J/B-AM FUSE
LEFT SEAT MEMORY SWITCH
LIGHT CONTROL SWITCH
LILL
LT BLU WIRE
LT GRN WIRE
MAIN BOARD MAP LIGHT ASSEMBLY
MAIN BODY ECU
MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY
PANEL FUSE
PNK ILLB WIRE
PNK RILL WIRE
PNK WIRE
POWER SWITCH
RED WIRE
RELAY ENERGIZED
RLMP
SPOT LIGHT ASSEMBLY
SWIL
TAIL
TAIL RELAY
USA CANADA
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Instrument illumination circuit (1 of 4) -> PNK ILLB WIRE
