Tire pressure monitoring circuit for Lexus RX III facelift (2012-2015)

1 2 3 4 5 6 IG 24 23 CANL CANH PNK WIRE 7 8 9 10 11 12 GND CLSW RDA BLK WIRE BRN WIRE CANN CANP COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM FUSE GAUGE 2 FUSE GRY WIRE HOT IN ON OR START INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) LT GRN WIRE RED WIRE TIRE PRESSURE WARNING ANTENNA, RECEIVER (REAR CENTER OF ROOF) TIRE PRESSURE WARNING ECU (BEHIND RIGHT SIDE OF DASH) TIRE PRESSURE WARNING RESET SWITCH VIO WIRE WHT WIRE WHT/BLK WIRE
