Lexus RX III facelift (2012-2015) right outer rearview mirror assembly Wiring diagram
This page shows the only wiring diagram for the component.right outer rearview mirror assembly, which is found in the car Lexus RX III facelift (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right outer rearview mirror assembly (1 of 1)
6 5 7 4 ER EL
BDSL
BDSR
BLB
BLGD
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BRB
BRGD
BRN WIRE
BSM
BSSW
BSTL
BSTR
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
ENGINE ROOM R/B ASSEMBLY (ON LEFT SIDE OF ENGINE COMPT)
FUSE
GAUGE 2 FUSE
GRN WIRE
GRY WIRE
HAZ FUSE
HEADLIGHT DIMMER SWITCH ASSEMBLY
HOT AT ALL TIMES
ILL ILL
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
L/P
LEFT "C" PILLAR)
LEFT BLIND SPOT MONITOR SENSOR (BEHIND LEFT SIDE OF REAR FASCIA)
LEFT OFF RIGHT
LEFT OUTER MIRROR CONTROL ECU ASSEMBLY (IN LEFT FRONT DOOR)
LEFT OUTER REARVIEW MIRROR ASSEMBLY
LT BLU WIRE
LT GRN WIRE
OMIL
OMIR
ORG/ WIRE
PNK CANH WIRE
PNK WIRE
RED WIRE
RELAY ENERGIZED
RIGHT BLIND SPOT MONITOR SENSOR (BEHIND RIGHT SIDE OF REAR FASCIA)
RIGHT OUTER MIRROR CONTROL ECU ASSEMBLY (IN RIGHT FRONT DOOR)
RIGHT OUTER REARVIEW MIRROR ASSEMBLY
TURN SIGNAL FLASHER ASSEMBLY (BEHIND LEFT SIDE OF DASH)
TURN SWITCH
VIO WIRE
WARNING CANCELING SWITCH ASSEMBLY
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Blind spot monitoring circuit -> RIGHT OUTER REARVIEW MIRROR ASSEMBLY
