Lexus RX III facelift (2012-2015) power back door main switch Wiring diagram
This page shows the only wiring diagram for the component.power back door main switch, which is found in the car Lexus RX III facelift (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power back door main switch (1 of 1)
13 5 15 14 OSR OSE OSL PAWL MSW
2 5 4 1 RSSI DATA +5 GND
5 15 16 RCO RDA RSSI
ASSEMBLY (BEHIND LEFT SIDE OF DASH)
BACK DOOR CONTROL SWITCH
BACK DOOR LOCK ASSEMBLY (LOWER CENTER OF BACK DOOR)
BACK DOOR OPENER SWITCH ASSEMBLY
BLK WIRE
BLU WIRE
BRN WIRE
BZR
CERTIFICATION ECU ASSEMBLY (RIGHT SIDE OF DASH)
COMPUTER CANN CANP DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM
CTY
DLSW
DOOR CONTROL RECEIVER
DOOR CONTROL SWITCH ASSEMBLY
ECU-B 1 FUSE
FSW+
GRN WIRE
GRY WIRE
HAF
HOT AT ALL TIMES
HOT IN ON OR START MAIN BODY ECU FUSE
HZSW
IG (LEFT REAR OF LUGGAGE COMPT) ECUB GND
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LEFT POWER BACK DOOR SENSOR (LEFT SIDE OF LIFTGATE)
LOCK
LT BLU WIRE
LT GRN WIRE
PBDS
PNK 1 2 WIRE
PNK 23 22 9 10 13 16 WIRE
PNK FUL WIRE
PNK WIRE
POS
POWER BACK DOOR MAIN SWITCH
POWER BACK DOOR UNIT ASSEMBLY (LEFT REAR OF ROOF)
RED WIRE
RIGHT POWER BACK DOOR SENSOR
TURN SIGNAL FLASHER
ULSW
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WIRELESS DOOR LOCK BUZZER (LEFT SIDE OF ENGINE COMPT)
YEL WIRE
Go to component -> Back door opener circuit -> POWER BACK DOOR MAIN SWITCH
