Lexus RX III facelift (2012-2015) nca blk Wiring diagram
This page shows the only wiring diagram for the component.nca blk, which is found in the car Lexus RX III facelift (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram nca blk (1 of 1)
AGND
ALO
ARO
ASGN
AUXO
BLK WIRE
BLU WIRE
BRN WIRE
DCM (TELEMATICS TRANSCEIVER) (W/ SAFETY CONNECT)
GRN (OR RED) WIRE
GRN WIRE
GRY WIRE
LT GRN WIRE
MACC
MCI-
MCO-
MCVD
MUTE
NCA BLK WIRE
NCA WIRE
OVERHEAD MODULE
PNK (OR BRN) WIRE
PNK WIRE
RED WIRE
RIGHT FRONT SPEAKER ASSEMBLY 2
RIGHT FRONT SPEAKER ASSEMBLY 3
SGND
SPI+
SPO-
STEREO JACK ADAPTER ASSEMBLY 1
TELEPHONE MICROPHONE
TWR+
UDO+
UJSG
UPI
W/ SAFETY CONNECT
W/O SAFETY CONNECT
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Radio circuit, without navigation with radio & display receiver type (3 of 4) -> NCA BLK WIRE
