Lexus RX III facelift (2012-2015) hold switch assembly Wiring diagram
This page shows the only wiring diagram for the component.hold switch assembly, which is found in the car Lexus RX III facelift (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hold switch assembly (1 of 1)
BLK WIRE
BLU WIRE
DOWN
DOWN FRONT
FDWN RCLF
FRONT
FRONT VERTICAL SLDR FUP
GRN WIRE
GRY WIRE
HOLD SWITCH ASSEMBLY
HOT AT ALL TIMES
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LDWN
LEFT FRONT LUMBAR SUPPORT FORWARD, BACK MOTOR ASSEMBLY (IN DRIVER'S SEAT BACK)
LEFT FRONT POWER SEAT
LEFT FRONT POWER SEAT LIFT POSITION MOTOR ASSEMBLY (UNDER DRIVER'S SEAT)
LEFT FRONT POWER SEAT RECLINING POSITION MOTOR ASSEMBLY (IN DRIVER'S SEAT BACK)
LEFT FRONT POWER SEAT SLIDE POSITION MOTOR ASSEMBLY (UNDER DRIVER'S SEAT)
LEFT FRONT POWER SEAT SWITCH
LEFT FRONT POWER SEAT VERTICAL POSITION MOTOR ASSEMBLY (UNDER DRIVER'S SEAT)
LIFTER
LT BLU WIRE
LT GRN WIRE
P-SEAT LH FUSE
PNK WIRE
RCLR LUP
REAR UP
RECLINING
RELEASE
SLDF
SLIDE
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Driver power seat circuit -> HOLD SWITCH ASSEMBLY
