Lexus RX III facelift (2012-2015) from engine room r/b assembly Wiring diagram
This page shows the only wiring diagram for the component.from engine room r/b assembly, which is found in the car Lexus RX III facelift (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram from engine room r/b assembly (1 of 1)
1 2 3 4 5 6 7 8 IG
1 2 4 17 5 7 FROM INSTRUMENT PANEL J/B ACCD (DIAGRAM 3 OF 4)
ALT B
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
D/L ALT B FUSE
D/L SOURCE RELAY
ECU-ACC FUSE
F/L DOOR FUSE
F/R DOOR FUSE
FR FOG FUSE
FR FOG RELAY
FROM
FROM ENGINE ROOM R/B ASSEMBLY
FROM ENGINE ROOM R/B ASSEMBLY (DIAGRAM 2 OF 4)
FROM INSTRUMENT PANEL J/B
FROM INSTRUMENT PANEL J/B (DIAGRAM 3 OF 4)
FROM TAIL FUSE (DIAGRAM 3 OF 4)
FUEL OPN FUSE
FUSE
GRN WIRE
GRY WIRE
INVERTER FUSE
INVERTER RELAY (LEFT 'C' PILLAR)
LEFT "C" PILLAR)
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU
MEMORY SYSTEMS
MIRRORS, MEMORY, POWER WINDOWS SYSTEMS
OBD FUSE
P-SEAT LH FUSE
P-SEAT RH FUSE
POWER MANAGEMENT CONTROL ECU
POWER OUTLET SOCKET ASSEMBLY
POWER SWITCH
POWER TOPS SYSTEM
POWER WINDOWS SYSTEM
PSB FUSE
RED WIRE
RELAY (DIAGRAM 3 OF 4)
RL DOOR
RR DOOR
S/ROOF FUSE
SEATS SYSTEM
SEATS, MEMORY SYSTEMS
SUPPLEMENTAL RESTRAINTS SYSTEM
TI, TE FUSE
TRUNK, TAILGATE, FUEL DOORS SYSTEM
VOLTAGE INVERTER (LEFT SIDE OF CARGO AREA)
WARNING, INSTRUMENT AIR CLUSTER CONDITIONING, SYSTEM NAVIGATION, SOUND SYSTEMS
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power distribution circuit (4 of 4) -> FROM ENGINE ROOM R/B ASSEMBLY
