Lexus RX III facelift (2012-2015) aron Wiring diagrams
This page contains all the electrical diagrams for the component. aron, in which he is found in the car Lexus RX III facelift (2012-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
aron wiring diagram (1 of 2)
ADPG
AGND
AIR
ARON
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DOOR LOCKS, ANTI-THEFT SYSTEMS
ECU-ACC FUSE
FRONT WIPER DEICER SWITCH
GAUGE 1 FUSE
GIVF
GRN WIRE
GRY WIRE
ILL
INSTRUMENT CLUSTER SYSTEM
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LEFT STEERING PAD SWITCH
LT BLU WIRE
LT GRN WIRE
MACC
MIN
MODE
MULTI- DISPLAY ASSEMBLY
NCA WIRE
OFF HOOK
ON HOOK
PASSENGER AIR BAG ON/OFF INDICATOR
PBEW
PBLT
PNK WIRE
RADIO 2 FUSE
RADIO, DISPLAY RECEIVER ASSEMBLY
RED WIRE
RELAY ENERGIZED
RIGHT STEERING PAD SWITCH
SEEK
SEUC
SGND
SPIRAL CABLE SUB-ASSEMBLY (IN STEERING COLUMN)
STEERING PAD SWITCH ASSEMBLY
SUPPLEMENTAL RESTRAINTS SYSTEM
SWG
VA-
VAL+
VAR+
VIO WIRE
VMTI
VOICE
VOLUME-
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Radio circuit, without navigation with radio & display receiver type (2 of 4) -> ARON
aron wiring diagram (2 of 2)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 GND
27 28 29 30 -SR -SL +SR +SL
ABFS
AIR
AIR BAG SENSOR ASSEMBLY (BELOW CENTER CONSOLE)
ARON
BBL- BBL+
BCL+
BDL-
BLK WIRE
BLU WIRE
BRN WIRE
CANL PAON
CASE)
COMPUTER DATA LINES SYSTEM
DK DK
DK+
FUSE
GRN WIRE
GRY WIRE
ICL-
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) GAUGE 2 FUSE
LEFT CURTAIN SHIELD AIR BAG ASSEMBLY (LEFT SIDE OF ROOF)
LEFT DOOR SIDE AIR BAG SENSOR (BASE OF LEFT "B" PILLAR)
LEFT FRONT SIDE AIR BAG SQUIB CIRCUIT (IN DRIVER'S SEAT BACK)
LEFT REAR AIR BAG SENSOR (LEFT "C" PILLAR)
LEFT REAR SIDE AIR BAG SQUIB CIRCUIT
LT GRN WIRE
MULTI INFORMATION DISPLAY ASSEMBLY PASSENGER AIR BAG ON/OFF INDICATOR
NAVIGATION RECEIVER ASSEMBLY PASSENGER AIR BAG ON/OFF INDICATOR
P- P+ D+ D-
P-AB
P-AB GSW PK+ PK-
PAON
PK-
POWER MANAGEMENT CONTROL ECU (LEFT SIDE OF DASH)
PRETENSIONER LEFT FRONT SEAT OUTER BELT ASSEMBLY (BASE OF LEFT "B" PILLAR)
PRETENSIONER OUTER LEFT REAR SEAT BELT ASSEMBLY 1 (LEFT "C" PILLAR)
RADIO, DISPLAY RECEIVER ASSEMBLY PASSENGER AIR BAG ON/OFF INDICATOR
RED WIRE
RELAY ENERGIZED
RL- RL+ LSP- LBE-
SECOND STEP
SFL-
SPIRAL CABLE SUB-ASSEMBLY (IN STEERING COLUMN)
SRL-
VIO WIRE
W/ RADIO RECEIVER TYPE
W/ RADIO, DISPLAY RECEIVER TYPE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Supplemental restraint circuit (1 of 2) -> ARON
