Lexus RX III facelift (2012-2015) 23 24 pnk computer data lines system canh canl wiring diagram
This page shows the only wiring diagram for the component.23 24 pnk computer data lines system canh canl, which is found in the car Lexus RX III facelift (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
23 24 pnk computer data lines system canh canl wiring diagram (1 of 1)
23 24 PNK COMPUTER DATA LINES SYSTEM CANH CANL WIRE
4 1 3 SIG ES MPX PNK WIRE
40 26 19 24 IG IG PNK PNK WIRE
ACAN
AUTO
BLK WIRE
BLK/ WHT WIRE
BLU WIRE
BRN WIRE
COMBINATION METER ASSEMBLY
FR WASH FUSE
FR WIP FUSE
FRONT WASHER SWITCH
FRONT WINDSHIELD WASHER MOTOR, PUMP ASSEMBLY (IN WASHER FLUID RESERVOIR)
FRONT WIPER SWITCH
FUSE
GRN WIRE
GRY WIRE
HEADLIGHT CLEANER CONTROL RELAY (BELOW RIGHT HEADLIGHT ASSEMBLY)
HOT IN ON OR START
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
J/C
LEVEL WARNING SWITCH (IN WASHER FLUID RESERVOIR)
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU (BEHIND LEFT SIDE OF DASH)
MIST
OFF
ORG/ WIRE
OVERHEAD MODULE
PNK FRWA WIRE
RAIN SENSOR (CENTER FRONT OF ROOF)
RED WIRE
TAIL
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WIG
WINDSHIELD WIPER MOTOR ASSEMBLY (LEFT REAR OF ENGINE COMPT)
WINDSHIELD WIPER SWITCH ASSEMBLY
YEL WIRE
Go to component -> Front wiper/washer circuit, with auto wiper system -> 23 24 PNK COMPUTER DATA LINES SYSTEM CANH CANL WIRE
