Car Wiring Diagrams for Steering column circuit for Lexus RX III (2008-2012)

3 2 IGE BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM ENGINE ROOM R/B ASSEMBLY (ON LEFT SIDE OF ENGINE COMPARTMENT) GAUGE 2 FUSE GRN WIRE HOT AT ALL TIMES ID CODE BOX (LEFT SIDE OF DASH) INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) LIN LIN 1 POWER MANAGEMENT CONTROL ECU (LEFT SIDE OF DASH) RED WIRE RELAY ENERGIZED SL/R SLP STEERING LOCK ACTUATOR ASSEMBLY (ON STEERING COLUMN) STR LOCK FUSE WHT/BLK WIRE YEL WIRE
