Car Wiring Diagrams for Immobilizer circuit for Lexus RX III (2008-2012)

1 2 3 4 5 6 7 8 B+ 20 21 11 IMO IMI PNK WIRE BLK WIRE BRN WIRE CERTIFICATION ECU ASSEMBLY (RIGHT SIDE OF DASH) EFII EFIO PNK WIRE ENGINE ROOM R/B ASSEMBLY (ON LEFT SIDE OF ENGINE COMPT) HOT AT ALL TIMES IMMOBI FUSE ID CODE BOX (LEFT SIDE OF DASH) INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) LIN LT GRN WIRE POWER MANAGEMENT CONTROL ECU (LEFT SIDE OF DASH) RED WIRE STEERING LOCK ACTUATOR ASSEMBLY (ON STEERING COLUMN) VIO WIRE WHT/BLK WIRE
