Lexus RX III (2008-2012) w/ w/o navigation navigation system system Wiring diagram
This page shows the only wiring diagram for the component.w/ w/o navigation navigation system system, which is found in the car Lexus RX III (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ w/o navigation navigation system system (1 of 1)
1 4 8 9 5 +B FSR- FSR+ BSW BGND
1 6 12 24 23 IG+ ES PBLT CANL CANH
16 24 FSR+ FSR-
18 10 LBE- LBE+
AIR BAG SENSOR ASSEMBLY (BELOW CENTER CONSOLE)
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM CANL CANH
FUSE
GAUGE 2 FUSE
GRN WIRE
GRY WIRE
HOT IN ON OR START
INSTRUMENT PANEL J/B ASSEMBLY (LEFT SIDE OF DASH)
LEFT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY (AT LEFT "B" PILLAR)
LEFT FRONT SEAT INNER BELT ASSEMBLY (UNDER DRIVER'S SEAT)
LT GRN WIRE
MAIN BODY ECU
OCCUPANT DETECTION ECU (UNDER FRONT PASSENGER'S SEAT)
ORG/ WIRE
PNK WIRE
RED WIRE
RIGHT FRONT SEAT INNER BELT ASSEMBLY (UNDER FRONT PASSENGER'S SEAT)
VIO WIRE
W/ W/O NAVIGATION NAVIGATION SYSTEM SYSTEM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Seat belt warning circuit -> W/ W/O NAVIGATION NAVIGATION SYSTEM SYSTEM
