Lexus RX III (2008-2012) sftd igsw imo vpmp Wiring diagram
This page shows the only wiring diagram for the component.sftd igsw imo vpmp, which is found in the car Lexus RX III (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sftd igsw imo vpmp (1 of 1)
ANTI-THEFT SYSTEM
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
C/OPN RELAY
COMPUTER DATA LINES SYSTEM INSTRUMENT CLUSTER SYSTEM
COOLING FANS SYSTEM RFC LGND CCS STA
CRUISE CONTROL SYSTEM
ECM (LEFT SIDE OF ENGINE COMPT)
EFI 1 FUSE
EFI MAIN F/PMP EFI 2 FUSE FUSE FUSE
EFI MAIN RELAY
ENGINE ROOM R/B ASSEMBLY (LEFT FRONT FENDER APRON)
F/PUMP RELAY
FPR MPMP
FUEL PUMP, FUEL SENDER GAUGE ASSEMBLY (TOP OF FUEL TANK)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER SYSTEM
LEFT QUARTERPANEL)
LT BLU WIRE
LT GRN WIRE
NEO
ORG/ WIRE
PNK ANTI-THEFT SYSTEM IMI WIRE
PNK CRUISE CONTROL SYSTEM WIRE
PNK WIRE
POWER MANAGEMENT CONTROL ECU (LEFT END OF DASH)
RED WIRE
SFTD IGSW IMO VPMP
STP CCHG SFTU
TACH TC
TRANSMISSION CONTROL ECU ASSEMBLY (LEFT FRONT OF ENGINE COMPT)
TRANSMISSION CONTROL SWITCH (UNDER CENTER CONSOLE)
VCPA EPA PNK WIRE
VIO WIRE
WARNING SYSTEMS COMPUTER DATA LINES SYSTEM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.5l (1 of 6) -> SFTD IGSW IMO VPMP
