Lexus RX III (2008-2012) power management Wiring diagram
This page shows the only wiring diagram for the component.power management, which is found in the car Lexus RX III (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power management (1 of 1)
8 3 4 2 PNK WIRE
BLK WIRE
BLU WIRE
BOF
BOR
BRN WIRE
CLEARANCE WARNING BUZZER 1 (CENTER OF DASH)
CLEARANCE WARNING ECU ASSEMBLY (RIGHT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
CONTROL ECU (LEFT SIDE OF DASH)
ENGINE ROOM R/B 2 (LEFT REAR OF ENGINE COMPT)
FUSE
GRN WIRE
HOT IN ON OR START
HOT W/ IGCT MAIN RELAY ENERGIZED
IGCT 3 FUSE
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LEFT ULTRASONIC
LEFT ULTRASONIC SENSOR 1 (LEFT FRONT CORNER OF ENGINE COMPT)
LEFT ULTRASONIC SENSOR 3 (BEHIND REAR BUMPER)
LT BLU WIRE
ORG/ WIRE
PARK/NEUTRAL POSITION SWITCH
PNK WIRE
POWER MANAGEMENT
RED WIRE
RIGHT ULTRASONIC SENSOR 1 (RIGHT FRONT CORNER OF ENGINE COMPT)
RIGHT ULTRASONIC SENSOR 2 (BEHIND REAR BUMPER)
RIGHT ULTRASONIC SENSOR 3 (BEHIND REAR BUMPER)
SENSOR 2 (BEHIND REAR BUMPER)
SOF BBZ EF
SOR
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Rear sonar circuit -> POWER MANAGEMENT
