Lexus RX III (2008-2012) pnk hssr Wiring diagram
This page shows the only wiring diagram for the component.pnk hssr, which is found in the car Lexus RX III (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk hssr (1 of 1)
1 10 9 LMVR LM+R LMHR
1 10 9 RMVR RM+R RMHR
14 8 9 BDR CANH CANP PNK WIRE
14 8 9 BDR CANN CAPN PNK WIRE
3 11 MR+ MR-
BDR
BLK WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
CANN
CANP
CERTIFICATION ECU ASSEMBLY (RIGHT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
EC+
ECU-B 2 FUSE
ENGINE ROOM R/B ASSEMBLY (ON LEFT SIDE OF
F/L DOOR FUSE
F/R DOOR FUSE
FRONT DOOR)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HTR
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LEFT OUTER MIRROR CONTROL ECU ASSEMBLY (IN LEFT FRONT DOOR)
LEFT OUTER REAR VIEW MIRROR ASSEMBLY (ON LEFT FRONT DOOR)
LT BLU WIRE
LT GRN WIRE
LVC
MAIN BODY ECU
MIRROR ADJUST SWITCH
MIRROR AUTO RETRACT SWITCH
MIRROR RETRACT SWITCH
MIRROR SELECT SWITCH +B
MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY
ORG/ WIRE
PNK HSSR WIRE
RED WIRE
RED/WHT WIRE
RIGHT OUTER MIRROR CONTROL ECU ASSEMBLY (IN RIGHT FRONT DOOR)
RIGHT OUTER REAR VIEW MIRROR ASSEMBLY (ON RIGHT
RVC
TRN+
VIO WIRE
VSSR
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Power mirrors circuit -> PNK HSSR WIRE
