Lexus RX III (2008-2012) pnk ffog Wiring diagram
This page shows the only wiring diagram for the component.pnk ffog, which is found in the car Lexus RX III (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk ffog (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 FLCL DIM LCTY LCYL
AIR BAG SENSOR ASSEMBLY (BELOW CENTER CONSOLE)
BLK WIRE
BLU WIRE
BRN WIRE
CANL CANH
CANN
CANP
CERTIFICATION NAVIGATION ECU ASSEMBLY RECEIVER (RIGHT SIDE ASSEMBLY OF DASH)
COMBINATION METER ASSEMBLY
CSPT
DOOR LOCKS SYSTEM
DOOR LOCKS SYSTEM INTERIOR LIGHTS SYSTEM
ECM (RIGHT FRONT OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HEAD TAIL
HEADLIGHTS SYSTEM
HEADLIGHTS SYSTEM INTERIOR LIGHTS SYSTEM DOOR LOCKS SYSTEM HEADLIGHTS SYSTEM
HU RCTY LSFL HF
INTERIOR LIGHTS SYSTEM HEADLIGHTS SYSTEM
LSFR BCTY CLTB CLTS CLTE
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU (BEHIND LEFT SIDE OF DASH)
ORG/ WIRE
PNK FFOG WIRE
PNK WIRE
POWER MANAGEMENT CONTROL ECU (LEFT SIDE OF DASH)
POWER STEERING ECU ASSEMBLY (LEFT END OF DASH)
RED WIRE
SKID CONTROL ECU ASSEMBLY (RIGHT SIDE OF DASH)
STEERING SENSOR (IN STEERING COLUMN)
VIO WIRE
W/ POWER BACK DOOR W/O POWER BACK DOOR
WHT WIRE
YAW RATE SENSOR ASSEMBLY (UNDER CENTER FLOOR CONSOLE)
YEL WIRE
Go to component -> Body control modules circuit (2 of 2) -> PNK FFOG WIRE
