Lexus RX III (2008-2012) pnk adim Wiring diagram
This page shows the only wiring diagram for the component.pnk adim, which is found in the car Lexus RX III (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk adim (1 of 1)
+ECU
30 13 BECU CANL
31 32 29 14 ALTB IG
ACAN
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CONSOLE BOX ILLUMINATION LIGHT ASSEMBLY
D/L ALT B FUSE
DC/DC FUSE
DISTANCE CONTROL
DOOR CONTROL SWITCH ASSEMBLY
ECU-B 1 FUSE
ENGINE ROOM R/B ASSEMBLY (ON LEFT SIDE OF ENGINE COMPT)
ENTER
FRONT WIPER DEICER SWITCH
FUSE
GAUGE 2 FUSE
GLOVE BOX LIGHT ASSEMBLY
GRN WIRE
GRY WIRE
HAZARD WARNING SIGNAL SWITCH ASSEMBLY
HEAD TAIL AUTO
HEATER CONTROL PANEL (RADIO RECEIVER ASSEMBLY) ADIM
HOOK
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START
ILL ILL
ILL- REMOTE OPERATION SWITCH
LEFT STEERING PAD SWITCH
LIGHT CONTROL SWITCH
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU INSTRUMENT PANEL J/B ASSEMBLY (LEFT SIDE OF DASH)
MENU
MODE
MONITOR
MULTI INFORMATION DISPLAY ASSEMBLY
MULTI- ILL DISPLAY ASSEMBLY
NAVIGATION RECEIVER ASSEMBLY (W/ NAVIGATION)
OFF (CANADA) DRL OFF (USA) HEADLIGHT DIMMER SWITCH ASSEMBLY
PANEL FUSE
PNK ADIM WIRE
PNK WIRE
RED WIRE
SEEK
SPIRAL CABLE SUB-ASSEMBLY (IN STEERING COLUMN)
STEERING PAD SWITCH ASSEMBLY
SWG
TAIL
TAIL RELAY
VIO WIRE
VOICE
VOLUME RIGHT STEERING PAD SWITCH
W/ NAVIGATION
W/O NAVIGATION
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Instrument illumination circuit (1 of 2) -> PNK ADIM WIRE
