Lexus RX III (2008-2012) left seat variable cushion switch Wiring diagrams
This page contains all the electrical diagrams for the component. left seat variable cushion switch, in which he is found in the car Lexus RX III (2008-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left seat variable cushion switch (1 of 2)
1 2 3 4 5 6 7 8 9 10 11 12 GND SLD+
6 3 4 GND FWD BACK
BLK WIRE
BLU WIRE
BRN WIRE
BUCKLE SWITCH
CANN
CANN CANP PRDC
CANP
COMPUTER DATA LINES SYSTEM
CSNF
CSNR
ENGINE ROOM R/B ASSEMBLY (ON LEFT SIDE OF OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HOLD
HOT AT ALL TIMES
HOT AT ALL TIMES ECU- B 1 FUSE
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LEFT FRONT LUMBAR SUPPORT FORWARD, BACK MOTOR ASSEMBLY
LEFT FRONT POWER SEAT CUSHION CONTROL MOTOR ASSEMBLY (UNDER DRIVER'S SEAT)
LEFT FRONT POWER SEAT LIFT POSITION MOTOR ASSEMBLY (UNDER DRIVER'S SEAT)
LEFT FRONT POWER SEAT RECLINING POSITION MOTOR ASSEMBLY (IN DRIVER'S SEAT BACK)
LEFT FRONT POWER SEAT SLIDE POSITION MOTOR ASSEMBLY (UNDER DRIVER'S SEAT)
LEFT FRONT POWER SEAT VERTICAL POSITION MOTOR ASSEMBLY (UNDER DRIVER'S SEAT)
LEFT FRONT SEAT INNER BELT ASSEMBLY (UNDER DRIVER'S SEAT)
LEFT FRONT SEAT OUTER BELT ASSEMBLY (BASE OF LEFT "B" PILLAR)
LEFT POWER SEAT FRONT SWITCH ASSEMBLY
LEFT SEAT VARIABLE CUSHION SWITCH
LFT- RCL-
LT BLU WIRE
LT GRN WIRE
MSWE
O/P
P-SEAT LH FUSE
PNK WIRE
RED WIRE
RELEASE
SEAT MEMORY SWITCH
SET-
SGND SSRS PVCC PBCL
SLD- FRV- +B FRV+ LFT+ RCL+
SYSB
VCC PNK WIRE
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Driver"s memory seat circuit -> LEFT SEAT VARIABLE CUSHION SWITCH
Wiring diagram left seat variable cushion switch (2 of 2)
