Lexus RX III (2008-2012) led type hid, halogen type Wiring diagram
This page shows the only wiring diagram for the component.led type hid, halogen type, which is found in the car Lexus RX III (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram led type hid, halogen type (1 of 1)
1 2 3 4 5 6 7 8 9 10 OUT
1 23 24 2 IG+ CANH CANL PNK WIRE
4 16 STPO
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
CRA+
DRIVING SUPPORT ECU ASSEMBLY
ENGINE ROOM R/B ASSEMBLY (ON LEFT SIDE OF ENGINE COMPT)
GAUGE 1 FUSE
GAUGE 2 FUSE
GRN WIRE
GRY WIRE
HAZ FUSE
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LED TYPE HID, HALOGEN TYPE
LEFT HEADLIGHT ASSEMBLY
LT BLU WIRE
LT GRN WIRE
MARKER
MARKER SIDE
PNK WIRE
POWER MANAGEMENT CONTROL ECU (LEFT END OF DASH)
RED WIRE
RIGHT HEADLIGHT ASSEMBLY
RIGHT OUTER MIRROR CONTROL ECU ASSEMBLY (IN RIGHT FRONT DOOR)
RIGHT OUTER REAR VIEW MIRROR ASSEMBLY
SHIFT LOCK CONTROL ECU SUB-ASSEMBLY
SIDE
SKID CONTROL ECU (RIGHT SIDE OF DASH)
STOP FUSE
STOP LIGHT CONTROL RELAY ASSEMBLY (LEFT END OF DASH)
STP +B
STP+
SWITCH ASSEMBLY
TOWING FUSE
TRN+
TRNI
TURN
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (3 of 3) -> LED TYPE HID, HALOGEN TYPE
