Lexus RX III (2008-2012) ldns lups Wiring diagrams
This page contains all the electrical diagrams for the component. ldns lups, in which he is found in the car Lexus RX III (2008-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram ldns lups (1 of 2)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 IG
ABSORBER CONTROL SWITCH
AIR SUS FUSE
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DOWN
FUSE
GRN WIRE
GRY WIRE
HEIGHT CONTROL VALVE HARNESS ASSEMBLY
HOT AT ALL TIMES
HOT IN RUN OR START ENGINE ROOM R/B ASSEMBLY (ON LEFT SIDE OF ENGINE COMPT)
INSTRUMENT PANEL J/B
LDNS LUPS
LEFT FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY (LEFT SIDE OF ENGINE COMPT)
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
RIGHT FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY (RIGHT SIDE OF ENGINE COMPT)
RM+
RM+ SHFR
SBR
SGR
SHB
SHFL
SHFR
SHG
SHRL
SLRL SLRR RM-
SUSPENSION CONTROL ECU (RIGHT SIDE OF DASH)
SUSPENSION CONTROL SWITCH
SUSPENSION CONTROL SWITCH 2
TD DNSW UPSW
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Electronic air suspension circuit (1 of 2) -> LDNS LUPS
Wiring diagram ldns lups (2 of 2)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 IG
ABSORBER CONTROL SWITCH
AIR SUS FUSE
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DOWN
FUSE
GRN WIRE
GRY WIRE
HEIGHT CONTROL VALVE HARNESS ASSEMBLY
HOT AT ALL TIMES
HOT IN RUN OR START ENGINE ROOM R/B ASSEMBLY (LEFT FRONT FENDER APRON)
INSTRUMENT PANEL J/B
LDNS LUPS
LEFT FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY (LEFT REAR OF ENGINE COMPT)
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
RIGHT FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY (RIGHT REAR OF ENGINE COMPT)
RM+
RM+ SHFR
SBR
SGR
SHB
SHFL
SHFR
SHG
SHRL
SLRL SLRR RM-
SUSPENSION CONTROL ECU (RIGHT SIDE OF DASH)
SUSPENSION CONTROL SWITCH
TD DNSW UPSW
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Electronic suspension circuit (1 of 2) -> LDNS LUPS
