Lexus RX III (2008-2012) efii efio pnk Wiring diagram
This page shows the only wiring diagram for the component.efii efio pnk, which is found in the car Lexus RX III (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram efii efio pnk (1 of 1)
1 2 3 4 5 6 7 8 B+
20 21 11 IMO IMI PNK WIRE
BLK WIRE
BRN WIRE
CERTIFICATION ECU ASSEMBLY (RIGHT SIDE OF DASH)
EFII EFIO PNK WIRE
ENGINE ROOM R/B ASSEMBLY (ON LEFT SIDE OF ENGINE COMPT)
HOT AT ALL TIMES IMMOBI FUSE
ID CODE BOX (LEFT SIDE OF DASH)
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LIN
LT GRN WIRE
POWER MANAGEMENT CONTROL ECU (LEFT SIDE OF DASH)
RED WIRE
STEERING LOCK ACTUATOR ASSEMBLY (ON STEERING COLUMN)
VIO WIRE
WHT/BLK WIRE
Go to component -> Immobilizer circuit -> EFII EFIO PNK WIRE
