Lexus RX III (2008-2012) computer data (right front lines system engine compt) wiring diagram
This page shows the only wiring diagram for the component.computer data (right front lines system engine compt), which is found in the car Lexus RX III (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
computer data (right front lines system engine compt) wiring diagram (1 of 1)
ABS 1 FUSE
ABS 2 FUSE
BLK WIRE
BLU WIRE
BM CANH
BRAKE PEDAL LOAD SENSING SWITCH (NEAR BRAKE PEDAL ASSEMBLY)
BRN WIRE
COMPUTER DATA (RIGHT FRONT LINES SYSTEM ENGINE COMPT)
COMPUTER DATA LINES SYSTEM
CSW STPO
ECU-B 1 FUSE
ENGINE ROOM R/B ASSEMBLY (LEFT FRONT FENDER APRON)
FSW+
FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LT GRN WIRE
ORG/ WIRE
OUT
PARKING BRAKE SWITCH ASSEMBLY (ON PARKING BRAKE ASSEMBLY)
PNK RL- RL+ FR- FR+ WIRE
PNK WIRE
RED WIRE
RELAY ENERGIZED
RR- RR+ FL- FL+
SKID CONTROL BUZZER ASSEMBLY (LEFT SIDE OF DASH)
SKID CONTROL ECU W/ ACTUATOR ASSEMBLY (RIGHT REAR OF ENGINE COMPT)
STOP FUSE
STOP LIGHT CONTROL RELAY ASSEMBLY (LEFT END OF DASH)
STOP LIGHT SWITCH ASSEMBLY (ON BRAKE PEDAL BRACKET)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit (1 of 2) -> COMPUTER DATA (RIGHT FRONT LINES SYSTEM ENGINE COMPT)
