Lexus RX III (2008-2012) canl computer data lines system Wiring diagram
This page shows the only wiring diagram for the component.canl computer data lines system, which is found in the car Lexus RX III (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram canl computer data lines system (1 of 1)
4 WHEEL DRIVE CONTROL SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
BSF
BSLC
CANH COMPUTER DATA LINES SYSTEM
CANL COMPUTER DATA LINES SYSTEM
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
CONSOLE)
FUSE
GAUGE FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT PANEL J/B ASSEMBLY (LEFT SIDE OF DASH)
LT BLU WIRE
NCA WIRE
OF CARGO AREA)
ORG/ WIRE
PNK CANH COMPUTER DATA LINES SYSTEM WIRE
REAR SEAT)
RED WIRE
SLC+
SLC+ CANH
SOLENOID (LEFT REAR OF VEHICLE)
SSLC SLC-
STEERING SENSOR (ON STEERING COLUMN)
WHT WIRE
WHT/BLK WIRE
YAW RATE SENSOR ASSEMBLY (LEFT SIDE OF CENTER
YEL WIRE
Go to component -> 4wd circuit -> CANL COMPUTER DATA LINES SYSTEM
