Lexus RX III (2008-2012) +b wf wig tail Wiring diagram
This page shows the only wiring diagram for the component.+b wf wig tail, which is found in the car Lexus RX III (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram +b wf wig tail (1 of 1)
+B WF WIG TAIL
23 24 PNK CANH CANL WIRE
4 1 3 SIG ES MPX
40 26 19 24 IG IG PNK WIRE
ACAN
AUTO
BLK WIRE
BLK/ WHT WIRE
BLU WIRE
BRN WIRE
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
FR WASH FUSE FUSE
FR WIP FUSE
FRONT WASHER SWITCH
FRONT WINDSHIELD WASHER MOTOR, PUMP ASSEMBLY (IN WASHER FLUID RESERVOIR)
FRONT WIPER SWITCH
GRN WIRE
GRY WIRE
HOT IN ON OR START
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
J/C
LEVEL WARNING SWITCH (IN WASHER FLUID RESERVOIR)
LT BLU WIRE
MAIN BODY ECU (BEHIND LEFT SIDE OF DASH)
MIST
OFF
ORG/ WIRE
OVERHEAD MODULE
RAIN SENSOR (CENTER FRONT OF ROOF)
RED WIRE
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WIPER MOTOR ASSEMBLY (LEFT REAR OF ENGINE COMPT)
WINDSHIELD WIPER SWITCH ASSEMBLY EW +S +1
YEL WIRE
Go to component -> Front wiper/washer circuit, with auto wiper system -> +B WF WIG TAIL
