Shift interlock circuit for Lexus RX II facelift (2006-2009)

1 2 3 4 5 6 7 8 9 10 11 12 IG BLK WIRE BLU WIRE ECU- IG 1 FUSE ECU-ACC FUSE GRN WIRE HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) J/B 3 (LEFT SIDE OF DASH) J/B 4 (RIGHT SIDE OF DASH) JUNCTION CONNECTOR 13 (CENTER OF DASH) JUNCTION CONNECTOR 7, 8 (BEHIND LEFT SIDE OF DASH) KEY INTERLOCK SOLENOID (LEFT SIDE OF DASH) KLS+ ORG/ WIRE P DETECTION SWITCH SHIFT LOCK ECU (UNDER CENTER CONSOLE, BESIDE SHIFT LEVER) SHIFT LOCK SOLENOID SLS+ STOP FUSE STOPLIGHT SWITCH WHT WIRE WHT/BLK WIRE YEL WIRE
