Car Wiring Diagrams for Passive restraints circuit for Lexus RX II facelift (2006-2009)

BLK WIRE BN (AT LEFT "B" PILLAR) BP (LOWER RIGHT "B" PILLAR) DRIVER'S SIDE BUCKLE SWITCH (ON LEFT SEAT BELT BUCKLE) FRONT PASSENGER'S SIDE BUCKLE SWITCH (IN SEAT BELT BUCKLE) GAUGE 1 FUSE GRN WIRE HOT IN ON OR START INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) J/C 45, 46 (IN DRIVER'S SEAT BOTTOM) J/C 47, 48 (UNDER PASSENGER'S SEAT) LEFT TENSION REDUCER SOLENOID (AT BASE OF LEFT "B" PILLAR) REAR J/B (LEFT REAR SIDE OF CARGO AREA) RIGHT TENSION REDUCER SOLENOID (AT BASE OF RIGHT "B" PILLAR) VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
