Lexus RX II facelift (2006-2009) pnk ig Wiring diagrams
This page contains all the electrical diagrams for the component. pnk ig, in which he is found in the car Lexus RX II facelift (2006-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram pnk ig (1 of 3)
1 5 26 16 28 GND
5 4 EC- EC+
7 15 5 2 ECI- ECI+ EC+ EC-
7 15 5 2 ECI- ECI+ EC+ EC- EC
7 6 5 4 3 2 1 IG
BLK WIRE
BLK/RED WIRE
BLU WIRE
EC+ EC-
ECU- IG 1 FUSE
GRY WIRE
HOT IN ON OR START
INNER MIRROR
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LEFT REMOTE CONTROL MIRROR
LEFT REMOTE LEFT REMOTE CONTROL CONTROL MIRROR MIRROR ECU (IN LEFT FRONT DOOR)
OVERHEAD J/B (FRONT CENTER OF ROOF)
PNK IG WIRE
PNK WIRE
RIGHT REMOTE CONTROL MIRROR
RIGHT REMOTE CONTROL MIRROR ECU (IN RIGHT FRONT DOOR)
W/ MEMORY
W/O MEMORY
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Electrochromic mirror circuit -> PNK IG WIRE
Wiring diagram pnk ig (2 of 3)
+B(DOME)
+B(DOME) MASTER WARNING IND
1 2 3 4 5 6 7 8 9 10 11 12 13 14 14 15 16 17 18 19 20 21 22 23 24 25 26 GND
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BUZZER
COMBINATION METER
DOME FUSE
DRIVE IC
ECU-IG 2 FUSE
FUSIBLE LINK BLOCK (LEFT SIDE OF ENGINE COMPT)
GAUGE 2 FUSE
GRN WIRE
GRY WIRE
HEADLIGHT BEAM LEVEL CONTROL ECU (BEHIND LEFT END OF DASH)
HEADLIGHTS CIRCUIT
HOT AT ALL TIMES
HOT IN ON OR START
IK (TOP LEFT SIDE OF DASH)
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
J/B 3 (LEFT SIDE OF DASH)
J/C 7, 8 (BEHIND LEFT SIDE OF DASH)
J/C 9 (BEHIND LEFT SIDE OF DASH)
LCD (MULTI DISPLAY)
LEFT HEADLIGHT
LEFT HEADLIGHT BEAM LEVEL CONTROL MOTOR
LT GRN WIRE
MICRO COMPUTER
ORG/ WIRE
PNK IG WIRE
PNK SPDL SPDR HDLP WIRE
PNK WIRE
POWER SUPPLY
RED WIRE
RHG
RIGHT HEADLIGHT BEAM LEVEL CONTROL MOTOR RIGHT HEADLIGHT
RIGHT REAR HEIGHT CONTROL SENSOR (AT RIGHT REAR SUSPENSION)
RLO
RRO
SBR WNG LHG
SGR
SHB
SHG
SHR
SHRR
SKID CONTROL ECU W/ ACTUATOR (RIGHT SIDE OF DASH)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Headlamps leveling circuit -> PNK IG WIRE
Wiring diagram pnk ig (3 of 3)
BLK WIRE
BLU WIRE
BODY ECU
BRN WIRE
COMBINATION SWITCH
DRL 4 RELAY
ECU-IG 2 FUSE
FRWA
FUSIBLE LINK BLOCK (LEFT SIDE OF ENGINE COMPARTMENT)
GRN WIRE
GRY WIRE
H-LP CLN FUSE
H-LP L LWR RELAY
H-LP R LWR RELAY
HDLO
HEAD
HEADLIGHT CLEANER CONTROL RELAY (BELOW RIGHT HEADLIGHT ASSEMBLY)
HEADLIGHT CLEANER MOTOR (BELOW RIGHT FRONT HEADLIGHT)
HEADLIGHT CLEANER SWITCH
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT IN ON OR START
HRLY HDLO
II (AT LEFT KICK PANEL)
IJ (LEFT TOP OF DASH)
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
J/B 2 (LEFT SIDE OF ENGINE COMPARTMENT)
J/B 3 (LEFT SIDE OF DASH)
JUNCTION CONNECTOR 13 (CENTER OF DASH)
JUNCTION CONNECTOR 18, 19 (RIGHT SIDE OF DASH)
JUNCTION CONNECTOR 2 (IN RIGHT FRONT OF ENGINE COMPT, BEHIND HEADLIGHT) EB
JUNCTION CONNECTOR 7, 8 (BEHIND LEFT SIDE OF DASH)
JUNCTION CONNECTOR 9 (BEHIND LEFT SIDE OF DASH)
LT GRN WIRE
MAIN FUSE
MODE MONITOR TERMINAL
OFF ON
OFF TAIL
PNK 9 22 20 8 WIRE
PNK IG WIRE
PNK WIRE
RED WIRE
SOLID STATE
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Headlamp washer circuit -> PNK IG WIRE
