Lexus RX II facelift (2006-2009) main battery ind Wiring diagram
This page shows the only wiring diagram for the component.main battery ind, which is found in the car Lexus RX II facelift (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram main battery ind (1 of 1)
+B(DOME)
+B(DOME) ILLUMINATION (RING)
ABS IND.
AFS OFF IND
BEAN
BLK WIRE
BLU WIRE
BRAKE CONTROL IND
BRAKE IND
BRN WIRE
BUZZER
CHARGE IND
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CRUISE IND
DOME FUSE
DOOR IND MASTER
DRIVER IC
DRIVER'S SEAT BELT IND
ECU-B 1 FUSE
ENGINE CONTROLS SYSTEM COMPUTER DATA LINES SYSTEM
ENGINE CONTROLS SYSTEM SOUND SYSTEMS HEADLIGHTS SYSTEM
FRONT FOG IND
FUEL
FUEL IND
FUEL SENDER (MAIN) (ON TOP OF FUEL TANK)
FUSIBLE LINK BLOCK
GRY WIRE
HEAD (USA) TAIL (EXCEPT IND USA) HIGH BEAM IND
HOT AT ALL TIMES
HOT IN ON OR START
II (AT LEFT KICK PANEL)
ILLUMINATION (MULTI DISPLAY)
ILLUMINATION IND (DIAL LCD) ILLUMINATION IND (POINTER)
INSTRUMENT GAUGE 2 FUSE PANEL J/B (LEFT SIDE OF DASH)
J/B 3 (LEFT SIDE OF DASH)
LCD (MULTI DISPLAY)
LEFT TURN IND
LT BLU WIRE
LT GRN WIRE
MAIN BATTERY IND
MALFUNCTION IND
MICRO COMPUTER
NAVIGATION SYSTEM
ORG/ WIRE
PNK EXTERIOR LIGHTS SYSTEM WIRE
PNK WIRE
POWER METER
POWER SUPPLY CIRCUIT
PS IND
READY IND
RED WIRE
RHEOSTAT
RHEOSTAT TRIP SWITCH
RIGHT TURN IND
SLIP IND
SPEEDOMETER
SRS IND
SW ODO/TRIP
TCAN SW
TEMPERATURE
TIRE PRESSURE IND
TRUNK, TAILGATE, FUEL DOORS SYSTEM
VIO WIRE
WARNING IND
WHT WIRE
WHT/BLK WIRE
WIPER/WASHER SYSTEM
YEL WIRE
Go to component -> Instrument cluster circuit (1 of 2) -> MAIN BATTERY IND
