Lexus RX II facelift (2006-2009) height control switch Wiring diagram
This page shows the only wiring diagram for the component.height control switch, which is found in the car Lexus RX II facelift (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram height control switch (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 SLRL SLRR
1 3 2 SHG SHB SHRR
3 1 2 SHG SHB SHRL
ACCESS MODE SWITCH
AFS ECU (BEHIND LEFT SIDE OF DASH)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DNSW UPSW
FLO FRO IG
GRN WIRE
GRY WIRE
HEIGHT CONTROL SWITCH
HSW
IGH
ILLUM
J/C 18, 19 (BEHIND RIGHT SIDE OF DASH)
J/C 34 (LEFT REAR OF VEHICLE, BEHIND REAR BUMPER)
LEFT FRONT HEIGHT CONTROL SENSOR (LEFT SIDE OF ENGINE COMPT)
LEFT REAR HEIGHT CONTROL SENSOR (AT LEFT REAR SUSPENSION)
LMSW
LSW
LT BLU WIRE
LT GRN WIRE
OFID HI NR LO LMID SIL
ORG/ WIRE
PNK WIRE
RED WIRE
RIGHT FRONT HEIGHT CONTROL SENSOR (RIGHT SIDE OF ENGINE COMPT)
RLO
RRO
SBR
SGR
SHB
SHFL
SHFR
SHFR SHFL
SHG
SHRL
SHRL SHRR RM+ RM-
SKID CONTROL ECU W/ ACTUATOR (RIGHT FRONT OF ENGINE COMPT)
SLLO SLEX SLFR SLFL
STP TACH
SUSPENSION CONTROL ECU (UNDER RIGHT SIDE OF DASH)
TS TC
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Electronic suspension circuit (1 of 2) -> HEIGHT CONTROL SWITCH
