Lexus RX II facelift (2006-2009) blw tsd tsp Wiring diagram
This page shows the only wiring diagram for the component.blw tsd tsp, which is found in the car Lexus RX II facelift (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram blw tsd tsp (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 IG
A/C AMPLIFIER (RIGHT SIDE OF DASH)
A/C ROOM
A/C SOLAR SENSOR (BEHIND UPPER LEFT SIDE OF DASH)
A/C THERMISTOR (LEFT SIDE OF DASH)
AIR AIF AOF AOD TPI TPO TPD TPP SG TE
AIR INLET CONTROL SERVO MOTOR (BEHIND RIGHT SIDE OF DASH)
AIR MIX CONTROL SERVO MOTOR (DRIVER SIDE) (BEHIND LEFT SIDE OF DASH)
AIR MIX CONTROL SERVO MOTOR (FRONT PASSENGER SIDE) (BEHIND RIGHT SIDE OF DASH)
AIR VENT MODE CONTROL SERVO MOTOR (BEHIND RIGHT SIDE OF DASH)
AMDC AMDH AMPC SG-4 SG-3 SG-2 SG-1
AMPH
BLK WIRE
BLU WIRE
BLW TSD TSP
BRN WIRE
COMPUTER DATA LINES SYSTEM
DEF
ECU- IG 1 FUSE
ECU-B 1 FUSE
FACE
FUSIBLE LINK BLOCK (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HEATER FUSE
HOT AT ALL TIMES
HOT IN ON OR START
HUMIDITY
II (AT LEFT KICK PANEL)
INSTRUMENT PANEL J/B
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
J/B 3 (LEFT SIDE OF DASH)
LT BLU WIRE
LT GRN WIRE
MCOOL
MFRS
MHOT
MPX+ MPX- WIP GND
MREC
ORG/ WIRE
PNK SSR+ WIRE
PNK WIRE
R/B 3 (LEFT SIDE OF ENGINE COMPT)
RED WIRE
SG-5
VIO WIRE
WATER PUMP FUSE
WHT WIRE
WHT/BLK WIRE
WIPER/WASHER SYSTEM
YEL WIRE
Go to component -> Automatic a/c circuit (1 of 2) -> BLW TSD TSP
