Car Wiring Diagrams for Heated seats circuit for Lexus RX II (2003-2006)

BLK WIRE BN (AT LEFT "B" PILLAR) BP (LOWER RIGHT "B" PILLAR) BRN WIRE DRIVER'S SEAT HEATER ECU- IG 1 FUSE FRONT PASSENGER'S SEAT HEATER (IN FRONT PASSENGER'S SEAT) GRY WIRE HOT IN ON OR START IJ (LEFT TOP OF DASH) INSTRUMENT PANEL J/B J/B 3 (LEFT SIDE OF DASH) J/B 4 (RIGHT SIDE OF DASH) JUNCTION CONNECTOR 13 (CENTER OF DASH) JUNCTION CONNECTOR 45, 46 (IN DRIVER'S SEAT BOTTOM) JUNCTION CONNECTOR 47, 48 (IN PASSENGER'S SEAT CUSHION) LT BLU WIRE ORG/ WIRE PNK WIRE RED WIRE RED/YEL WIRE RVL RVR SEAT HEATER SWITCH SEAT HTR FUSE SWL SWR WHT/BLK WIRE YEL WIRE
