Lexus RX II (2003-2006) tire pressure warning standardization switch Wiring diagram
This page shows the only wiring diagram for the component.tire pressure warning standardization switch, which is found in the car Lexus RX II (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tire pressure warning standardization switch (1 of 1)
A/C AMPLIFIER
AFS OFF SWITCH
AIR BAG SENSOR ASSEMBLY
AIR BAG SENSOR ASSEMBLY COMBINATION METER
AUTO WIPER ECU
BLK WIRE
COMBINATION METER
COMBINATION SWITCH
DATA LINK CONNECTOR 3
ELECTRONICALLY CONTROLLED TRANSMISSION PATTERN SELECT SWITCH
FRONT INTERIOR LIGHT
GATEWAY ECU
GLOVE BOX LIGHT
HEIGHT CONTROL OFF SWITCH
HEIGHT CONTROL SWITCH ACCESS MODE SWITCH TRANSMISSION CONTROL SWITCH
II (AT LEFT KICK PANEL)
IK (TOP LEFT SIDE OF DASH)
IM (AT RIGHT KICK PANEL)
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) BODY ECU
J/B 3 (LEFT SIDE OF DASH)
J/B 4 (RIGHT SIDE OF DASH)
JUNCTION CONNECTOR 11 (BEHIND LEFT SIDE OF DASH)
JUNCTION CONNECTOR 13 (CENTER OF DASH)
JUNCTION CONNECTOR 14, 15 (CENTER OF DASH)
KEY INTERLOCK SOLENOID
MOON ROOF CONTROL ECU LEFT VANITY LIGHT
MULTI-MODE SHIFT LEVER TYPE
NORMAL TYPE MOON ROOF MULTI PANEL TYPE MOON ROOF
OVERHEAD J/B
POWER BACK DOOR OPENER/ CLOSER SWITCH
RAIN SENSOR
RELAY
RIGHT VANITY LIGHT
SEAT HEATER SWITCH SUSPENSION CONTROL ECU
SHIFT LOCK ECU
STEERING ANGLE SENSOR
TILT MOTOR
TIRE PRESSURE WARNING STANDARDIZATION SWITCH
TO GROUND IJ (DIAGRAM 4 OF 4)
TO JUNCTION CONNECTOR 13 (DIAGRAM 4 OF 4)
TRACTION OFF SWITCH CIGARETTE LIGHTER
TRANSPONDER KEY COMPUTER
TURN SIGNAL FLASHER
UNLOCK WARNING SWITCH
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (3 of 4) -> TIRE PRESSURE WARNING STANDARDIZATION SWITCH
