Lexus RX II (2003-2006) left front scuff plate light Wiring diagram
This page shows the only wiring diagram for the component.left front scuff plate light, which is found in the car Lexus RX II (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front scuff plate light (1 of 1)
BACK DOOR COURTESY LIGHT
BACK DOOR LOCK ASSEMBLY
BLK WIRE
BR (LEFT REAR CARGO AREA)
BRN WIRE
CTYO
DIODE 1
DIODE 2
DIODE 3
GRN WIRE
GRY WIRE
J/B 3 (LEFT SIDE OF DASH)
J/B 4 (RIGHT SIDE
JUNCTION CONNECTOR 28, 29 (IN LEFT FRONT DOOR)
JUNCTION CONNECTOR 30, 31 (LEFT REAR OF VEHICLE)
JUNCTION CONNECTOR 32, 33 (IN RIGHT FRONT DOOR)
JUNCTION CONNECTOR 36
JUNCTION CONNECTOR 40 (RIGHT REAR OF CARGO AREA)
LEFT FRONT DOOR COURTESY LIGHT
LEFT FRONT INSIDE HANDLE ILLUMINATION (W/ STEP LIGHT)
LEFT FRONT SCUFF PLATE LIGHT
LEFT REAR INSIDE HANDLE ILLUMINATION (W/ STEP LIGHT)
LEFT REAR SCUFF PLATE LIGHT
LEFT STEP LIGHT
LT BLU WIRE
LT GRN WIRE
LUGGAGE COMPARTMENT LIGHT
OF DASH)
ORG/ WIRE
PNK PNK CTYE WIRE
PNK WIRE
POWER BACK DOOR ECU (CENTER OF LEFT "D" PILLAR)
REAR INTERIOR LIGHT
REAR J/B (LEFT REAR SIDE OF CARGO AREA)
RED WIRE
RIGHT FRONT DOOR COURTESY LIGHT
RIGHT FRONT INSIDE HANDLE ILLUMINATION (W/ STEP LIGHT)
RIGHT FRONT SCUFF PLATE LIGHT
RIGHT REAR INSIDE HANDLE ILLUMINATION
RIGHT REAR SCUFF PLATE LIGHT
RIGHT STEP LIGHT
TRANSPONDER KEY AMPLIFIER
VIO WIRE
W/ STEP LIGHT
W/O POWER BACK DOOR W/ POWER BACK DOOR
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> LEFT FRONT SCUFF PLATE LIGHT
